Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | SCB100-S2 |
| Manufacturer | Yokogawa |
| Series | CENTUM VP / ProSafe-RS Accessories |
| Product Type | Field Wiring Diagnostic Element |
| Function | Open-circuit detection component for digital input field wiring diagnostics |
| Application | Digital input monitoring in DCS/SIS systems |
| Installation Method | Connected in parallel with field contact output |
| Diagnostic Purpose | Detects field wiring open-circuit faults while monitoring normally-OFF signals |
| Signal Type | Dry contact digital input circuits |
| Compatibility | Yokogawa CENTUM VP and ProSafe-RS digital input modules |
| Mounting Location | Installed near field equipment |
| Maintenance | Passive device, no configuration required |
| Operating Environment | Industrial process automation applications |
| Dimensions (L × W × H) | ≈ 50 × 15 × 10 mm |
| Weight | ≈ 0.02 kg |
FAQ
FAQ
Q1: What is SCB100-S2 used for?
It is used to detect open-circuit wiring faults in Yokogawa digital input circuits.
Q2: Which Yokogawa systems use SCB100-S2?
It is used with Yokogawa CENTUM VP and ProSafe-RS field wiring diagnostic functions.
Q3: How is SCB100-S2 connected?
It is connected in parallel with the contact output of the field equipment.
Q4: What type of fault does it detect?
It detects open-circuit (wire break) conditions in field wiring.
Q5: What type of signals is it designed for?
It is intended for normally-OFF dry contact digital input signals.
Q6: Does SCB100-S2 require power?
No, it is a passive diagnostic component and does not require a separate power supply.
Q7: What is the difference between SCB100-S2 and SCB110-S2?
SCB100-S2 is used for open-circuit detection on normally-OFF inputs, while SCB110-S2 is used for short-circuit detection on normally-ON inputs.
Q8: What are its dimensions and weight?
Typical dimensions are approximately 50 × 15 × 10 mm, with a weight of about 0.02 kg.
