Technical Specifications
| Item | Description |
|---|---|
| Model | SDV531-S23 |
| Number of Outputs | 8 channels, module isolation |
| Output Voltage | 24 V DC |
| Output Voltage Drop | Max. 1 V |
| Rated External Power | 24 V DC, minimum 5 A |
| External Power Range | 24 V DC +20% / -10% |
| Max Leak Current (Off) | 1.6 mA |
| Output Format | Current source output |
| Max Load Current | 0.6 A per channel (total max 4.8 A) |
| Min Load Current | 35 mA |
| Load Resistance Range | 40 to 685 Ω |
| Output Response Time | Max. 30 ms |
| Withstand Voltage | 2 kV AC between signal lines and system (8 lines) |
| Power Consumption | Max. 280 mA (5 V DC), 140 mA (24 V DC) |
| External Connection | Pressure clamp, MIL cable, or signal cable (AKB331) |
| Dimensions (W x H x D) | 130 x 107.5 x 32.8 mm |
| Weight | 0.28 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum output current of the SDV531-S23?
A1: The maximum output current is 0.6 A per channel, up to 4.8 A total across 8 channels.
Q2: What type of output format does the module support?
A2: The module uses a current source output format.
Q3: What is the leak current when the output is off?
A3: The maximum leak current in the off state is 1.6 mA.
Q4: What is the operating voltage range?
A4: The external power supply should be 24 V DC with a tolerance of +20% / -10%.
Q5: What load resistance range is supported?
A5: The module supports a load resistance range of 40 to 685 Ω.
Q6: Is the module electrically isolated?
A6: Yes, the SDV531-S23 is a module-isolated digital output unit.
Q7: What is the typical output response time?
A7: The maximum output response time is 30 milliseconds.
Q8: What connection options are available?
A8: The module can be connected via pressure clamp terminals, MIL cables, or dedicated signal cables such as AKB331.
