Technical Specifications
| Parameter | Value |
|---|---|
| Product Name | Yokogawa YS150-012 Single-loop Multi-Function Controller |
| Type | Single-loop Digital Controller |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Power Consumption | 20 VA |
| Input Signal | Analog input (4–20 mA, 0–10 V, configurable) |
| Output Signal | Analog output (4–20 mA, 0–10 V) + Relay output |
| Control Method | PID / Feedforward / Program control |
| Communication | RS-485 (Modbus RTU) |
| Display | High-brightness LCD digital display |
| Dimensions | 96 x 96 x 132 mm |
| Weight | 0.45 kg |
| Operating Environment | 0–50 ℃, 20–90% RH (non-condensing) |
| Mounting Method | Panel-mounted |
FAQ
FAQ
Q1: What control methods does this controller support?
A1: The YS150-012 supports PID control, feedforward compensation, and program control.
Q2: What types of input and output interfaces are available?
A2: Inputs include analog signals (4–20 mA, 0–10 V), while outputs include analog signals and relay contacts.
Q3: What are the dimensions and weight of this controller?
A3: The unit measures 96 x 96 x 132 mm and weighs 0.45 kg.
Q4: How is this device installed?
A4: It is designed for standard panel-mounted installation, making it easy to integrate into control cabinets.
Q5: Does the controller have communication capabilities?
A5: Yes, it is equipped with an RS-485 interface and supports the Modbus RTU protocol.
Q6: What are the operating environmental conditions?
A6: It operates within 0–50 ℃ temperature and 20–90% RH, non-condensing.
Q7: What type of display does it use?
A7: The controller features a high-brightness LCD digital display for clear visibility.
Q8: What is the power supply requirement?
A8: It operates on 100–240 V AC, 50/60 Hz.
