Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | 07NG81 GJR5213300R0006 |
| Manufacturer | ABB |
| Product Type | Power Supply Module |
| Series | Procontrol / Industrial Automation System |
| Application | PLC and Industrial Control Systems |
| Function | Provides regulated DC power to control modules |
| Input Voltage | 115/230 VAC |
| Output Voltage | 24 VDC |
| Output Current | Up to 5 A (typical) |
| Frequency | 50/60 Hz |
| Protection | Overvoltage, overload, and short-circuit protection |
| Cooling Method | Natural convection |
| Mounting Type | Rack or panel mounted |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 260 mm × 180 mm × 90 mm |
| Weight | Approx. 2.5 kg |
| Compliance | Industrial automation standards |
FAQ
FAQ
Q1. What is the function of the 07NG81 module?
It supplies stable 24 VDC power to industrial control and PLC systems.
Q2. Which systems is this power supply designed for?
It is typically used within ABB Procontrol and related industrial automation platforms.
Q3. What input voltage does the unit support?
The module operates on 115/230 VAC at 50/60 Hz.
Q4. What protections are built into the device?
It includes overvoltage, overload, and short-circuit protection features.
Q5. How is the module installed?
It can be mounted in a control cabinet using rack or panel mounting methods.
Q6. What is the operating temperature range?
The recommended operating range is 0°C to 55°C.
Q7. What are the physical dimensions and weight?
The unit measures approximately 260 mm × 180 mm × 90 mm and weighs about 2.5 kg.
Q8. Is this module suitable for continuous industrial operation?
Yes, it is designed for reliable long-term use in industrial automation environments.
