Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | Analog Input Module |
| Model Number | AIN300 P-HB-AIN-30010 000 |
| Brand | ABB Bailey |
| Module Type | Analog Input |
| Input Signal Types | 0–20 mA, 4–20 mA, 0–10 VDC, ±10 VDC |
| Input Impedance | 100 Ω for current, >100 kΩ for voltage |
| Accuracy | ±0.05% of full scale |
| Resolution | 16-bit A/D conversion |
| Sampling Rate | 10 ms per channel |
| Isolation | Channel-to-channel and channel-to-ground isolated |
| Temperature Range | 0°C to 70°C operating, -20°C to 85°C storage |
| Humidity | 5% to 95% non-condensing |
| Response Time | 10 ms typical |
| Communication | Backplane connection to Bailey control system |
| Diagnostics | Overrange, underrange, and fault detection for each channel |
| Power Supply | Supplied via system backplane |
| Mounting | Rack or panel mount compatible |
| Compliance | CE, UL certified |
| Dimensions | 266 x 76 x 162 mm |
| Weight | 1.7 kg |
FAQ
FAQ
Q1: What types of signals does the AIN300 support?
A1: It supports analog signals including 0–20 mA, 4–20 mA, 0–10 VDC, and ±10 VDC.
Q2: How accurate is the module?
A2: The module provides ±0.05% full-scale accuracy with 16-bit resolution.
Q3: Does the module provide diagnostic functions?
A3: Yes, it supports overrange, underrange, and fault detection for each channel.
Q4: How is the module powered?
A4: Power is supplied via the system backplane when installed in a compatible rack.
Q5: Can it operate in humid environments?
A5: Yes, it can operate in 5% to 95% non-condensing humidity conditions.
Q6: What is the typical response time for signals?
A6: The typical response time is 10 milliseconds per channel.
Q7: How does it interface with the Bailey control system?
A7: It connects through the backplane for seamless integration with the control system.
Q8: Is the module compatible with standard Bailey racks?
A8: Yes, it is compatible with standard Bailey control racks and can be mounted in a rack or panel.
