Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IMDSM05 |
| Manufacturer | ABB Bailey |
| Product Type | Digital I/O Slave Module |
| I/O Channels | 16 digital inputs, 16 digital outputs |
| Input Voltage Range | 24 V DC nominal (18–32 V DC) |
| Input Type | Optically isolated digital inputs |
| Output Type | Relay or transistor outputs (depending on configuration) |
| Output Voltage Range | 24 V DC nominal |
| Output Current Capacity | 0.5 A per channel (max) |
| Isolation Voltage | 500 V DC channel-to-ground isolation |
| Logic Levels | “1” ≥ 15 V DC, “0” ≤ 5 V DC |
| Power Supply Voltage | 24 V DC |
| Power Consumption | 5 W typical |
| Update Rate | 10 ms typical |
| Communication Interface | Bailey INFI 90 I/O Bus |
| Diagnostics | Channel fault detection and communication status indication |
| Mounting Type | Rack or panel mounting |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Compliance | CE, UL, and CSA certified |
| Dimensions | 271 × 150 × 30 mm |
| Weight | 0.22 kg |
FAQ
FAQ
Q1: What is the primary function of the IMDSM05 module?
The IMDSM05 serves as a digital I/O slave module, providing both input and output interfaces for discrete signal processing within ABB Bailey control systems.
Q2: How many digital channels does the IMDSM05 provide?
The module supports 16 digital input channels and 16 digital output channels for flexible control applications.
Q3: What type of input and output configurations are supported?
It supports optically isolated digital inputs and relay or transistor outputs, depending on system configuration.
Q4: How is isolation achieved between channels and system ground?
Each channel provides 500 V DC isolation from the system ground, ensuring noise immunity and safe operation.
Q5: What communication bus is used by the IMDSM05?
The IMDSM05 communicates over the Bailey INFI 90 I/O bus, ensuring compatibility with existing control architectures.
Q6: Does the IMDSM05 feature any built-in diagnostics?
Yes, it includes diagnostic functions for fault detection, communication verification, and channel health monitoring.
Q7: What is the update rate of the IMDSM05 module?
The typical update rate is around 10 milliseconds, suitable for fast-response digital control applications.
Q8: What environmental conditions can the IMDSM05 operate under?
The module is designed to operate between 0°C and 60°C with relative humidity up to 95% non-condensing.
