Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IMASM04 |
| Manufacturer | ABB Bailey |
| Product Type | Analog Input Slave Module |
| Input Channels | 16 analog input channels |
| Signal Types Supported | 0–20 mA, 4–20 mA, ±10 V DC |
| Input Impedance | > 250 Ω current input, > 100 kΩ voltage input |
| Accuracy | ±0.1% of full scale |
| Resolution | 12-bit A/D conversion |
| Sampling Rate | 50 samples per second per channel |
| Isolation Voltage | 500 V DC channel-to-ground isolation |
| Power Supply Voltage | 24 V DC nominal (18–32 V DC range) |
| Power Consumption | 3 W typical |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Communication Interface | Proprietary Bailey I/O bus |
| Diagnostics | Channel fault detection and signal validation |
| Mounting Type | DIN rail or module rack mounting |
| Compliance | CE, UL, and CSA certified |
| Dimensions | 178 × 51 × 230 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: What is the main function of the IMASM04 module?
The IMASM04 functions as an analog input slave module designed to receive and process analog signals from field instruments for use in ABB Bailey control systems.
Q2: How many analog input channels does the IMASM04 support?
It supports 16 isolated analog input channels, each configurable for current or voltage signals.
Q3: What types of analog signals can this module handle?
The IMASM04 accepts standard industrial analog signals such as 0–20 mA, 4–20 mA, and ±10 V DC.
Q4: What level of measurement accuracy does the IMASM04 provide?
It provides an accuracy of ±0.1% of full scale, ensuring precise and reliable signal conversion.
Q5: Does the module feature channel-to-ground isolation?
Yes, it provides 500 V DC isolation between input channels and ground to prevent signal interference.
Q6: What communication interface does the IMASM04 use?
It communicates via the Bailey proprietary I/O bus for integration within the INFI 90 or Net 90 control systems.
Q7: Does the IMASM04 include diagnostic capabilities?
Yes, it features self-diagnostics for signal validation, fault detection, and communication integrity monitoring.
Q8: What are the typical operating environmental conditions for the IMASM04?
The module operates reliably between 0°C and 60°C with a humidity range of 5% to 95% non-condensing.
