Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IMRAI12 |
| Manufacturer | ABB Bailey |
| Product Type | Non-Isolated Input Module |
| Input Channels | 12 analog input channels |
| Signal Types Supported | 0–20 mA, 4–20 mA, 0–10 V DC |
| Input Impedance | 100 Ω for current inputs, 10 kΩ for voltage inputs |
| Accuracy | ±0.2% of full scale |
| Resolution | 12-bit A/D conversion |
| Input Response Time | 10 ms typical |
| Diagnostics | Channel monitoring and fault detection |
| Power Supply Voltage | 24 V DC nominal (18–32 V DC range) |
| Power Consumption | 3.5 W typical |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | Rack-mounted |
| Compliance | CE, UL certified |
| Dimensions | 140 × 110 × 50 mm |
| Weight | 0.5 kg |
FAQ
FAQ
Q1: What is the main purpose of the IMRAI12 module?
The IMRAI12 is a non-isolated input module designed to acquire analog signals from field devices and transmit them to ABB Bailey control systems.
Q2: How many input channels are available on the IMRAI12?
It provides 12 analog input channels for connecting multiple field sensors.
Q3: What types of analog signals can the IMRAI12 handle?
It supports standard industrial signals such as 0–20 mA, 4–20 mA, and 0–10 V DC.
Q4: What is the measurement accuracy of the IMRAI12?
The module provides an accuracy of ±0.2% of full scale for precise signal conversion.
Q5: Does the IMRAI12 include diagnostic features?
Yes, it has built-in diagnostics for channel monitoring, fault detection, and signal validation.
Q6: What is the typical response time for the module?
The typical input response time is 10 milliseconds, allowing for fast signal processing.
Q7: Can the IMRAI12 operate in industrial environments with high humidity?
Yes, it functions reliably in humidity conditions ranging from 5% to 95% non-condensing.
Q8: What is the power supply requirement for the IMRAI12?
The module requires a 24 V DC power supply, with an acceptable range of 18–32 V DC.
