Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IMRCC01 |
| Manufacturer | ABB Bailey |
| Product Type | CPU Processor |
| Processor Type | 32-bit high-performance microprocessor |
| Memory | 2 MB RAM, 1 MB Flash EPROM |
| I/O Capacity | Supports multiple analog and digital I/O modules |
| Communication Interface | INFI 90 Bus, Local Bus, optional Ethernet |
| Control Functions | PID, logic, sequence, arithmetic operations |
| Scan Time | 5 ms typical |
| Redundancy Support | Dual-redundant operation supported |
| Diagnostics | Self-test, communication monitoring, fault detection |
| Real-Time Clock | Integrated with battery backup |
| Power Supply Voltage | 24 V DC nominal (18–32 V DC range) |
| Power Consumption | 7 W typical |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | Rack-mounted |
| Compliance | CE, UL, CSA certified |
| Dimensions | 260 × 120 × 45 mm |
| Weight | 0.85 kg |
FAQ
FAQ
Q1: What is the primary function of the IMRCC01?
The IMRCC01 serves as the central CPU processor, executing control algorithms, PID loops, and coordinating communication between I/O modules and the control network.
Q2: Which communication interfaces are supported by the IMRCC01?
It supports the INFI 90 Bus, Local Bus for I/O modules, and optional Ethernet for integration with external systems.
Q3: Does the IMRCC01 support redundancy?
Yes, it can operate in a dual-redundant configuration to ensure continuous system operation.
Q4: What control functions can the IMRCC01 perform?
It handles PID control, logic sequences, arithmetic operations, and other complex control tasks.
Q5: What diagnostic features are included in the IMRCC01?
The CPU includes self-tests, communication monitoring, and fault detection for high system reliability.
Q6: What is the typical scan time of the IMRCC01?
The typical control scan cycle is approximately 5 milliseconds, supporting fast and responsive control.
Q7: Can the IMRCC01 operate in challenging industrial environments?
Yes, it is designed to function reliably from 0°C to 60°C and within 5% to 95% non-condensing humidity.
Q8: How does the IMRCC01 handle timekeeping during power interruptions?
It features an integrated real-time clock with battery backup to maintain accurate time and critical process data during power loss.
