Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ABB Bailey NDSM02 |
| Type | Digital Slave Input Module |
| Function | Collects and transmits discrete digital input signals to the control processor in INFI 90 systems |
| Number of Input Channels | 16 isolated digital input channels |
| Input Signal Type | Dry contact or DC voltage input |
| Input Voltage Range | 0–32 VDC |
| Logic Level (ON/OFF) | ON > 15 VDC, OFF < 5 VDC |
| Input Impedance | 10 kΩ typical |
| Isolation Voltage | 1500 V RMS channel-to-ground |
| Update Rate | 10 ms typical |
| Communication Interface | Module Bus compatible with INFI-NET |
| Power Supply Voltage | 24 VDC nominal |
| Power Consumption | <8 W |
| Signal Conditioning | Integrated debounce and noise suppression circuitry |
| Diagnostic Features | Channel fault detection, self-test diagnostics, LED fault indication |
| Status Indication | Individual LED indicators per input channel |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5%–95% non-condensing |
| Cooling Method | Natural convection |
| Mounting Type | DIN-rail or card rack installation |
| Dimensions (HxWxD) | 150 × 150 × 50 mm |
| Weight | 0.5 kg |
FAQ
FAQ
Q1: What is the main function of the ABB Bailey NDSM02 module?
A1: The NDSM02 serves as a digital slave input module that interfaces field digital signals to the INFI 90 distributed control system for monitoring and logic operations.
Q2: How many digital inputs are supported by the NDSM02?
A2: It provides 16 optically isolated digital input channels, ensuring signal reliability and protection against noise interference.
Q3: What types of input signals can be connected to the NDSM02?
A3: The module supports both dry contact and DC voltage input signals, offering flexibility in various control applications.
Q4: How does the NDSM02 ensure signal stability?
A4: The module is equipped with noise suppression filters, debounce logic, and channel isolation to guarantee accurate and stable digital signal acquisition.
Q5: Does the NDSM02 include diagnostic capabilities?
A5: Yes, it features onboard self-diagnostics, channel fault monitoring, and LED indicators that display operational and fault statuses.
Q6: How does the NDSM02 communicate with other system modules?
A6: Communication occurs via the high-speed Module Bus, which connects the module to the system’s controller within the INFI-NET network.
Q7: What power supply is required for the NDSM02?
A7: The module operates with a 24 VDC nominal power input and typically consumes less than 8 watts during normal operation.
Q8: What are the typical applications for the NDSM02 module?
A8: The NDSM02 is commonly used in industrial process automation, power plants, and manufacturing systems to acquire discrete signals from switches, alarms, and safety interlocks.
