Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ABB Bailey NDSO04 |
| Type | Digital Slave Output Module |
| Function | Receives commands from a master module and provides discrete digital output signals to field devices |
| Number of Output Channels | 32 isolated digital output channels |
| Output Type | DC voltage or dry contact |
| Output Voltage Range | 0–32 VDC |
| Output Current | 0–500 mA per channel (typical) |
| Logic Level (ON/OFF) | ON > 15 VDC, OFF < 5 VDC |
| Isolation Voltage | 1500 V RMS channel-to-ground |
| Update Rate | 10 ms typical |
| Communication Interface | INFI-NET Module Bus as a slave module |
| Power Supply Voltage | 24 VDC nominal |
| Power Consumption | <12 W |
| Signal Conditioning | Integrated short-circuit and overcurrent protection |
| Diagnostic Features | Channel fault detection, self-test diagnostics, LED fault indication |
| Status Indication | Individual LED indicators per output channel |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5%–95% non-condensing |
| Cooling Method | Natural convection |
| Mounting Type | DIN-rail or card rack installation |
| Dimensions (HxWxD) | 150 × 150 × 50 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: What distinguishes the NDSO04 from standard output modules?
A1: The NDSO04 is a slave module that receives output commands from a master module rather than operating independently.
Q2: How many output channels are available on the NDSO04?
A2: It provides 32 isolated digital output channels.
Q3: What types of devices can the NDSO04 drive?
A3: It can drive relays, alarms, solenoids, and other digital field devices.
Q4: Are there protection features for the outputs?
A4: Yes, each channel has integrated short-circuit and overcurrent protection.
Q5: Does the NDSO04 support diagnostics?
A5: Yes, it provides channel fault detection, self-test diagnostics, and LED status indication.
Q6: What communication interface does the NDSO04 use?
A6: It uses the INFI-NET Module Bus to communicate as a slave module.
Q7: What is the power requirement for the NDSO04?
A7: The module requires a 24 VDC nominal power supply and consumes less than 12 W.
Q8: In which industrial applications is the NDSO04 typically used?
A8: It is commonly used in process automation, power generation, and industrial control systems to control output devices remotely.
