Technical Specifications
| Parameter | Description |
|---|---|
| Model | 1MRK002133-ACr03 |
| Type | Binary Input/Output Module |
| Input Type | Digital Input |
| Output Type | Digital Output |
| Supply Voltage | 24 V DC |
| Communication Interface | PROFIBUS / Modbus (optional) |
| Maximum Input Current | 10 mA |
| Maximum Output Current | 500 mA |
| Response Time | 1 ms |
| Operating Temperature | -20 ℃ to +60 ℃ |
| Storage Temperature | -40 ℃ to +85 ℃ |
| Dimensions | 180 × 120 × 40 mm |
| Weight | 0.35 kg |
| Mounting | DIN Rail |
| Protection Degree | IP20 |
FAQ
FAQ
-
Q1: How many input and output signals can the module handle simultaneously?
A1: The module supports up to 16 digital inputs and 16 digital outputs. -
Q2: What is the operating voltage range of the module?
A2: Standard operating voltage is 24 V DC with ±10% tolerance. -
Q3: Does the module support hot-swapping?
A3: No, it must be installed or replaced with the power off. -
Q4: Can the module operate in high-temperature environments?
A4: The module supports up to 60℃; additional cooling is needed if exceeded. -
Q5: What is the communication response time?
A5: Standard response time is approximately 1 ms, suitable for most automation applications. -
Q6: Are special tools needed for installation?
A6: No special tools are required; it can be mounted directly on a DIN rail. -
Q7: Which industrial protocols are supported?
A7: Optional support for PROFIBUS or Modbus, depending on configuration. -
Q8: What is the maintenance interval for the module?
A8: Maintenance-free design; however, a yearly inspection is recommended to ensure secure connections.
