Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | ABB 1MRK002247-AGr00 |
| Manufacturer | ABB |
| Product Series | Relion® Protection and Control IED Accessories |
| Product Type | Transformer Module (TRM) |
| Function | Provides current and voltage transformer interfaces for ABB protection and control relays |
| Application | Substation automation, feeder protection, transformer protection, generator protection, and industrial power distribution |
| Current Transformer Inputs | 6 Current Inputs (6I), 1 A rated |
| Voltage Transformer Inputs | 6 Voltage Inputs (6U) |
| Rated Current | 1 A |
| Rated Voltage | 110/220 VAC |
| Frequency | 50/60 Hz |
| Terminal Type | Compression terminals |
| Compatible Equipment | ABB Relion® protection and control IEDs |
| Mounting Type | Internal plug-in module |
| Communication | Internal interface with the host ABB protection relay |
| Operating Environment | Industrial and utility substation applications |
| Construction | Industrial-grade transformer interface module |
| Country of Origin | Sweden |
| Dimensions | Approx. 240 × 170 × 45 mm |
| Weight | Approx. 1.0 kg |
FAQ
FAQ
Q1: What is the ABB 1MRK002247-AGr00 used for?
A: The 1MRK002247-AGr00 is a transformer module used to interface current transformers (CTs) and voltage transformers (VTs) with ABB Relion protection relays for measurement, monitoring, and protection functions.
Q2: How many current and voltage inputs does the module provide?
A: The module provides 6 current inputs (1 A) and 6 voltage inputs, making it suitable for a wide range of power protection applications.
Q3: Which ABB systems are compatible with the 1MRK002247-AGr00?
A: It is designed for ABB Relion protection and control IED platforms used in substations, power plants, and industrial electrical distribution systems.
Q4: Is the 1MRK002247-AGr00 a protection relay?
A: No. It is a transformer interface module that works together with an ABB protection relay. The protection logic is executed by the host IED.
Q5: What are the electrical ratings of the module?
A: The module supports 1 A CT inputs, 110/220 VAC voltage inputs, and operates at 50/60 Hz, making it suitable for standard utility protection applications.
Q6: What are the dimensions and weight of the 1MRK002247-AGr00?
A: The approximate dimensions are 240 × 170 × 45 mm, and the weight is approximately 1.0 kg. Actual values may vary slightly depending on the hardware revision and packaging.
Q7: Does the 1MRK002247-AGr00 require software configuration?
A: Yes. The module is configured through ABB Relion engineering software, where CT/VT ratios and protection parameters are assigned according to the application.
Q8: What should be checked before installing the 1MRK002247-AGr00?
A: Verify the part number, CT and VT ratings, terminal wiring, hardware revision, relay compatibility, and ensure the protection panel is completely de-energized before installation.
