Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | ABB 1MRK000284-ABr02 |
| Manufacturer | ABB |
| Product Series | Relion® Protection and Control IED Platform |
| Product Type | Binary Input Module (BIM) |
| Function | Acquires and processes digital input signals from field devices for protection, monitoring, and automation applications |
| Application | Substation automation, power system protection, transformer protection, feeder protection, and industrial automation |
| Input Channels | 24 optically isolated binary input channels |
| Input Type | Galvanically isolated digital inputs |
| Input Voltage | 24–250 V AC/DC (depending on system configuration) |
| Status Indication | Individual LED indicator for each input channel |
| Communication | Operates through the host ABB Relion IED using IEC 61850, DNP3, Modbus, and other supported protocols |
| Compatible Equipment | ABB Relion® protection relays including RED670, REL670, REB670, RET670, and compatible IEDs |
| Mounting Type | Plug-in module for ABB protection relay chassis |
| Protection Class | IP20 |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Construction | Industrial-grade PCB with optically isolated input circuits |
| Dimensions | Approx. 233 × 166 × 15 mm |
| Weight | Approx. 0.20 kg |
FAQ
FAQ
Q1: What is the ABB 1MRK000284-ABr02 used for?
A: The 1MRK000284-ABr02 is a Binary Input Module used to collect digital signals from switches, circuit breakers, protection devices, and other field equipment for ABB Relion protection and control systems.
Q2: How many input channels does the module provide?
A: The module provides 24 independent optically isolated binary input channels, allowing reliable monitoring of multiple field signals simultaneously.
Q3: Which ABB systems are compatible with the 1MRK000284-ABr02?
A: It is designed for ABB Relion protection relays and is commonly used with devices such as RED670, REL670, REB670, RET670, and other compatible IEDs.
Q4: Is the 1MRK000284-ABr02 a protection relay?
A: No. It is an I/O expansion module that supplies binary input functions. Protection algorithms are executed by the host Relion relay.
Q5: What types of signals can the module receive?
A: It accepts digital status signals from field devices such as circuit breakers, disconnect switches, auxiliary contacts, push buttons, and alarm contacts.
Q6: What are the dimensions and weight of the 1MRK000284-ABr02?
A: The approximate dimensions are 233 × 166 × 15 mm, and the weight is approximately 0.20 kg. Actual values may vary slightly depending on packaging.
Q7: Does the 1MRK000284-ABr02 require software configuration?
A: Yes. The module is configured through the ABB Relion engineering tools, where each binary input can be assigned to specific monitoring, protection, or control functions.
Q8: What should be checked before installing the 1MRK000284-ABr02?
A: Verify the part number, hardware revision, relay compatibility, input voltage requirements, field wiring, and ensure the protection system is de-energized before installing or replacing the module.
