Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | ABB 1MRK000614-ABr01 |
| Manufacturer | ABB |
| Product Type | Binary Output Module |
| Product Series | ABB Power Automation / Protection and Control IED Accessories |
| Function | Provides relay output interfaces for switching and control operations in ABB protection and automation systems |
| Application | Substation automation, power system protection, industrial control, and electrical distribution systems |
| Module Type | Binary Output Module (BOM) |
| Output Channels | 24 Output Relays |
| Output Type | Relay contact outputs |
| Relay Configuration | 24 independent binary output relays |
| Main Function | Provides electrical isolation and switching control between protection devices and external circuits |
| Compatible Equipment | ABB protection and control IED systems |
| Communication Interface | Internal ABB IED module connection |
| Installation Type | Internal module installation in ABB protection/control equipment |
| Mounting Method | Plug-in module mounting |
| Power Supply | Supplied by the host ABB protection and control system |
| Operating Environment | Industrial substation and automation environment |
| Construction | Industrial-grade electronic module assembly |
| Replacement Application | Used as a replacement binary output module for compatible ABB systems |
| Product Weight | Approx. 0.52 kg |
| Dimensions | Approx. 138 × 60 × 15 mm |
| Weight | Approx. 0.04–0.52 kg depending on configuration and packaging |
FAQ
FAQ
Q1: What is the ABB 1MRK000614-ABr01 used for?
A: The ABB 1MRK000614-ABr01 is a binary output module used to provide relay output channels for control, signaling, and switching functions in ABB protection and automation systems.
Q2: How many output relays does the ABB 1MRK000614-ABr01 provide?
A: The module provides 24 relay output channels for external control and indication applications.
Q3: Is ABB 1MRK000614-ABr01 a protection relay?
A: No. It is an accessory I/O expansion module. The main protection functions are performed by the connected ABB protection and control device.
Q4: Where is the ABB 1MRK000614-ABr01 commonly installed?
A: It is mainly installed in ABB power automation, substation protection, and industrial control systems where additional binary output points are required.
Q5: Can ABB 1MRK000614-ABr01 replace another output module directly?
A: Replacement depends on the complete part number, hardware version, host ABB device model, and system configuration. Compatibility should be confirmed before installation.
Q6: What are the dimensions and weight of ABB 1MRK000614-ABr01?
A: The approximate dimensions are 138 × 60 × 15 mm, and the weight is about 0.52 kg for the module assembly. Actual values may vary depending on packaging and hardware version.
Q7: Does ABB 1MRK000614-ABr01 require software configuration?
A: The module does not operate independently. Output functions are configured through the connected ABB protection or control system settings.
Q8: What should be checked before installing ABB 1MRK000614-ABr01?
A: Confirm the ABB device compatibility, module position, relay output wiring, system configuration, and ensure the equipment is powered off before replacement.
