Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | 560PSU01 R0002 |
| Part Number | 1KGT006600R0002 |
| Product Type | Power Supply Unit |
| System | ABB RTU560 |
| Application | RTU560 power supply racks |
| Input Voltage | 110–220 VDC |
| Input Tolerance | -20% / +15% |
| Output Voltage | 5.1 VDC and 24 VDC |
| 5 VDC Output Current | 0.2–5.5 A |
| 24 VDC Output Current | 0–0.7 A |
| Total Output Power | 44.3 W |
| Efficiency | Approx. 62% |
| Input Current | Approx. 0.6–0.3 A |
| Operating Temperature | 0–70 °C |
| Relative Humidity | 5–95%, non-condensing |
| Protection | Reverse-voltage protection, galvanic isolation, short-circuit/electronic power protection |
| Mounting | RTU560 rack-mounted |
| Compatible Racks | 560MPR03 / 560SFR02 |
| Connector | 48-pin Type F DIN 41612 |
| Dimensions | Approx. 160 × 100 mm, 3U Eurocard format |
| Product Net Weight | Approx. 0.48 kg |
| Gross Weight | Approx. 0.55 kg |
FAQ
FAQ
Q1: What is ABB 560PSU01 R0002?
A: It is a power supply unit for ABB RTU560 remote terminal unit racks.
Q2: What is the ABB part number?
A: The part number is 1KGT006600R0002, with the commercial designation 560PSU01 R0002.
Q3: What is the input voltage?
A: The nominal input range is 110–220 VDC, with an input tolerance of approximately -20% to +15%.
Q4: What outputs does it provide?
A: It provides 5.1 VDC and 24 VDC outputs. The 5.1 V output can supply up to 5.5 A, while the 24 V output can supply up to 0.7 A.
Q5: What is the total output power?
A: The total rated output power is 44.3 W.
Q6: Which RTU560 racks are compatible?
A: It is specifically designed for RTU560 racks, including 560MPR03 and 560SFR02, and can be used in redundant power-supply configurations.
Q7: What are the dimensions and weight?
A: The technical data describes the unit as a 160 mm × 100 mm, 3U Eurocard-format PCB. The product net weight is approximately 0.48 kg, with gross weight around 0.55 kg.
Q8: Can two 560PSU01 units be used redundantly?
A: Yes. The 560PSU01 is designed for redundant operation in RTU560 racks, allowing a second power-supply unit to provide continuity if the primary unit fails.
