Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 5SHX2645L0002 / 3BHB012961R0002 |
| Product Type | IGCT Module (Integrated Gate-Commutated Thyristor) |
| Voltage Rating | 4500 V |
| Maximum Current | 4000 A |
| Turn-On Time | ≤1 μs |
| Turn-Off Time | ≤1 μs |
| Power Dissipation | Low-loss design |
| Package Type | Heatsink mountable |
| Cooling Method | Forced air or liquid cooling |
| Applications | Medium-voltage drives, industrial rectifiers, power systems |
| Dimensions | 120 x 26 x 120 mm |
| Weight | 1.32 kg |
FAQ
FAQ
Q1: What are the main applications of the ABB 5SHX2645L0002 IGCT module?
A1: It is mainly used in medium-voltage drives, industrial rectifiers, power converters, and high-power supply systems.
Q2: What are the rated voltage and current of this module?
A2: The rated voltage is 4500 V, and the maximum current is 4000 A.
Q3: What is the difference between IGCT and IGBT?
A3: IGCT offers faster switching and lower conduction losses, ideal for high-voltage, high-current use; IGBT is more suitable for medium-power applications.
Q4: What cooling methods does the ABB IGCT module support?
A4: It supports forced air cooling and liquid cooling, depending on the system requirements.
Q5: What should be considered when installing the module?
A5: Ensure proper thermal contact, use a compatible heatsink, and implement ESD protection during installation.
Q6: What are the turn-on and turn-off times of the IGCT?
A6: Both turn-on and turn-off times are typically ≤1 μs, providing excellent dynamic performance.
Q7: Can the ABB 5SHX2645L0002 be used in parallel to increase current capacity?
A7: Yes, the module can be paralleled for higher current output, but proper gate drive synchronization and thermal/current balancing must be ensured.
Q8: What are the physical dimensions and weight of the module?
A8: The module measures 120 x 26 x 120 mm and weighs 1.32 kg.
