| Item | Specification |
|---|---|
| Model | ABB AO561 (Ordering No. 1TNE968902R1201) |
| Type | Analog Output Module |
| Product Category | PLC / DCS I/O Module |
| Product Family | ABB Advant Controller / S900 I/O system |
| Function | Provides isolated analog output signals for control and monitoring |
| Number of Output Channels | 6 channels |
| Output Signal Types | 0–10 V, 4–20 mA (configurable per channel) |
| Output Resolution | High-resolution industrial analog conversion |
| Output Accuracy | High precision for process control |
| Output Load Capability | Supports standard analog loads (voltage or current) |
| Isolation | Galvanic isolation between channels and system backplane |
| Status Indication | LED indicators for module and channel status |
| Mounting Method | DIN rail mounting or rack mount via terminal base |
| Field Wiring Connection | Screw terminal or plug-in terminal base |
| Operating Temperature Range | –20 °C to +55 °C |
| Storage Temperature Range | –40 °C to +70 °C |
| Protection Rating | IP20 |
| Housing Material | Industrial-grade plastic |
| Application Environment | Industrial automation and process control cabinets |
| Compatibility | ABB S900 / Advant Controller I/O systems |
| Dimensions | Approx. 20 mm × 104 mm × 104 mm (W × H × D) |
| Weight | Approximately 0.22 kg |
FAQ
FAQ
Q1: What is the primary function of the ABB AO561 module?
It provides multiple isolated analog output channels used to generate control signals for actuators, valves, drives, and other field devices in industrial control systems.
Q2: How many analog output channels does the AO561 provide?
The module offers six independent analog output channels.
Q3: What types of analog signals can the AO561 output?
Each channel can be configured for standard analog output formats such as 0–10 V or 4–20 mA.
Q4: Does the module provide electrical isolation?
Yes, it provides galvanic isolation between channels and the backplane to improve signal integrity and safety.
Q5: How are the output signals connected to field devices?
Output signals connect via screw terminal blocks or a plug-in terminal base for secure field wiring.
Q6: Does the AO561 include status indicators?
Yes, it includes LED indicators to show module power status and individual channel activity or fault conditions.
Q7: Is this module suitable for use in industrial environments?
Yes, it is designed for installation in industrial control cabinets and automation systems within standard temperature ranges.
Q8: What are the physical dimensions and weight of the AO561?
The module measures approximately 20 mm × 104 mm × 104 mm and weighs about 0.22 kg.
