Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Analog Output Module |
| Part Number | AO845 |
| Product ID (Ordering Code) | 3BSE023676R1 |
| Number of Channels | 8 channels |
| Signal Type | Current |
| Output Range | 0…20 mA / 4…20 mA |
| Load Impedance | ≤ 750 Ohm |
| Accuracy | ±0.2% of span |
| Resolution | 12 bits |
| Update Time | < 1 ms/channel |
| Isolation | Channel-to-bus and channel-to-channel |
| Power Consumption | 1.2 W |
| Voltage Range | 24 V DC (19.2…30 V DC) |
| Diagnostics | Yes |
| Module Mounting | DIN rail mounting |
| Dimensions | 45 × 102 × 119 mm |
| Weight | 0.21 kg |
| Operating Temperature | -25 to +70 °C |
| Storage Temperature | -40 to +70 °C |
| Relative Humidity | 5% to 95%, non-condensing |
FAQ
FAQ
Q1: What type of output signal does the AO845 module support?
A1: The AO845 supports current outputs of 0–20 mA and 4–20 mA.
Q2: Is there isolation between the output channels in AO845?
A2: Yes, it provides both channel-to-channel and channel-to-bus isolation.
Q3: What is the output accuracy of AO845?
A3: The module delivers ±0.2% of span accuracy.
Q4: What is the maximum load impedance the AO845 can support?
A4: The module supports up to 750 Ohm of load impedance.
Q5: What is the resolution of the AO845 output signal?
A5: It offers 12-bit resolution for precise analog output.
Q6: Does AO845 support diagnostic features?
A6: Yes, the module has built-in diagnostics for status monitoring.
Q7: What voltage supply is recommended for AO845?
A7: The recommended voltage is 24 V DC, with a range of 19.2 to 30 V DC.
Q8: How is the AO845 module installed?
A8: It is designed for easy DIN rail mounting in automation systems.
