Technical Specifications
| Item | Specification |
|---|---|
| Model | ABB BC810 (Ordering No. 3BSE031154R1) |
| Type | Analog Input/Output Channel Base Module |
| Product Category | PLC / DCS I/O Base Unit |
| Product Family | ABB S800 I/O System |
| Function | Provides power, communication, and terminal interface for I/O modules |
| Supported Module Types | Analog input and analog output modules |
| Module Slots | 1 channel slot (single module base) |
| Power Supply | Provides field and backplane supply for installed I/O modules |
| Signal Terminals | Screw-type terminals for field wiring |
| Communication Interface | Backplane connection to controller rack or bus |
| Status Indication | LEDs for base power and module presence |
| Mounting Method | DIN rail or panel mounting |
| Operating Temperature Range | –20 °C to +60 °C |
| Storage Temperature Range | –40 °C to +70 °C |
| Protection Rating | IP20 |
| Housing Material | Industrial-grade plastic |
| Application Environment | Industrial automation and control cabinets |
| Compatibility | ABB S800 I/O modules and compatible PLC/DCS controllers |
| Dimensions | Approx. 22 mm × 115 mm × 90 mm (W × H × D) |
| Weight | Approximately 0.15 kg |
FAQ
FAQ
Q1: What is the primary function of the ABB BC810 base module?
It provides a mounting base and electrical interface for a single channel analog I/O module in the ABB S800 I/O system.
Q2: What type of modules does the BC810 support?
It supports analog input or analog output I/O modules from the ABB S800 series.
Q3: How are field signals connected through the BC810?
Field wiring connects via screw-type terminals on the base to the installed I/O module.
Q4: Does the base module provide status indication?
Yes, it includes LEDs to show base power and module presence status.
Q5: How is the BC810 mounted in a control cabinet?
The base is mounted on a DIN rail or panel inside an industrial automation cabinet.
Q6: What power does the BC810 provide?
It distributes required supply voltage to the installed I/O module and backplane communication interface.
Q7: Can the BC810 operate in harsh industrial environments?
Yes, it is designed for industrial automation and control cabinet use within the specified temperature range.
Q8: What are the physical dimensions and weight of the BC810?
The base unit is approximately 22 mm wide, 115 mm high, 90 mm deep, and weighs about 0.15 kg.
