Technical Specifications
| Item | Specification |
|---|---|
| Model | ABB BCU-02 (Ordering No. 3AUA0000110429) |
| Type | Breaker Control Unit / Monitoring & Protection Interface |
| Product Category | Protection & Control Module |
| Product Family | ABB Auxiliary Control / Protection devices |
| Function | Provides automated breaker control, status monitoring, and auxiliary logic interface |
| Control Inputs | Digital control inputs for breaker open/close commands |
| Status Outputs | Discrete outputs for breaker position and alarm indications |
| Auxiliary Contacts | Monitored breaker auxiliary contact inputs |
| Protection Interface | Integration with protection relays and interlock logic |
| Communication Interface | Discrete logic and auxiliary contact interface |
| Mounting Method | DIN rail or panel mounting inside control cabinets |
| Field Wiring Connection | Screw terminal connectors for power, inputs, outputs |
| Supply Voltage | DC control supply (e.g., 24 V DC typical) |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Protection Rating | IP20 |
| Housing Material | Industrial-grade plastic |
| Application Environment | Motor control centers, switchgear, automation panels |
| Compatibility | Circuit breakers with auxiliary contacts and discrete control logic |
| Dimensions | Approx. 90 mm × 70 mm × 60 mm (W × H × D) |
| Weight | Approximately 0.25 kg |
FAQ
FAQ
Q1: What is the primary function of the ABB BCU-02?
It provides automated breaker control and status monitoring, interfacing breaker auxiliary contacts with control system logic.
Q2: What kinds of signals does the BCU-02 handle?
It handles digital control inputs (breaker open/close) and discrete status outputs (breaker position and alarms).
Q3: How is the BCU-02 connected to field devices?
Field devices connect through screw terminals for inputs, outputs, and auxiliary contacts.
Q4: What supply voltage does the unit use?
It typically uses a DC control supply, such as 24 V DC.
Q5: Does the BCU-02 provide protection features?
It integrates with protection relays and auxiliary logic circuits to help manage breaker operation safely.
Q6: Where is the BCU-02 typically installed?
It is installed inside motor control cabinets, switchgear, or automated panels near breaker control wiring.
Q7: Can the BCU-02 operate in industrial environments?
Yes, it is designed for use in industrial automation environments within its rated temperature range.
Q8: What are the physical dimensions and weight of the BCU-02?
The control unit measures approximately 90 mm × 70 mm × 60 mm and weighs about 0.25 kg.
