Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | ABB D685A1156U01 |
| Manufacturer | ABB |
| Product Series | ProcessMaster / HygienicMaster Electromagnetic Flowmeter |
| Product Type | Universal Backplane Board |
| Function | Provides internal connection interface and mounting support between transmitter electronics and field housing components |
| Application | ABB electromagnetic flowmeter systems, including FEX300 and FEX500 series transmitters |
| Main Function | Supports signal connection, power distribution, and communication interface between internal electronic assemblies |
| Compatible Equipment | ABB ProcessMaster FEP300/FEP500, HygienicMaster FEX300/FEX500 transmitter systems |
| Board Type | Backplane / Interface PCB Assembly |
| Installation Type | Installed inside dual-compartment transmitter housing |
| Connection Interface | Internal electrical connector interface |
| Housing Compatibility | Dual-compartment transmitter field housing |
| Mounting Method | Internal fixed mounting inside transmitter enclosure |
| Operating Environment | Industrial process measurement applications |
| Construction | Industrial-grade PCB assembly with connector interfaces |
| Protection Application | Used in flow measurement transmitters for process industries |
| Replacement Application | Replacement backplane board for compatible ABB electromagnetic flowmeter transmitters |
| Dimensions | Approx. 160 × 120 × 30 mm |
| Weight | Approx. 0.3 kg |
FAQ
FAQ
Q1: What is the ABB D685A1156U01 used for?
A: The ABB D685A1156U01 is a universal backplane board used inside ABB electromagnetic flowmeter transmitter housings. It provides electrical connection and mechanical support for internal transmitter components.
Q2: Which ABB products are compatible with D685A1156U01?
A: The module is mainly used with ABB ProcessMaster and HygienicMaster electromagnetic flowmeter transmitter systems, including FEX300 and FEX500 series equipment.
Q3: Is the ABB D685A1156U01 a measurement module?
A: No. It is a backplane/interface board. The actual flow measurement processing is performed by the transmitter electronics connected to this board.
Q4: What is the main function of the D685A1156U01 backplane?
A: The board provides internal signal routing, electrical connections, and mounting support between transmitter modules installed inside the dual-compartment housing.
Q5: Can D685A1156U01 replace another ABB backplane board directly?
A: Replacement should be confirmed by checking the complete ABB part number, transmitter model, housing type, and hardware revision before installation.
Q6: What are the dimensions and weight of ABB D685A1156U01?
A: The approximate dimensions are 160 × 120 × 30 mm, and the weight is about 0.3 kg. Actual values may vary slightly depending on revision and packaging.
Q7: Does D685A1156U01 require software configuration?
A: No. The backplane itself does not contain application software. Configuration is handled by the connected ABB flowmeter transmitter electronics.
Q8: What should be checked before installing ABB D685A1156U01?
A: Verify the transmitter model compatibility, inspect connectors and wiring, confirm the housing type, and disconnect power before replacing the backplane board.
