Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | ABB RETA-02 |
| Part Number | 68840830 / 3ABD68840830 |
| Manufacturer | ABB |
| Product Type | Ethernet Adapter Module |
| Product Series | ABB Drive Communication Options |
| Function | Provides Ethernet-based communication between ABB drives and industrial automation networks |
| Application | Motor control systems, industrial automation, drive monitoring, parameter access, and remote control |
| Compatible Drives | ABB ACS550, ACS800, ACS850, ACSM1, DCS800 and related ABB drive systems |
| Supported Protocols | PROFINET IO, Modbus/TCP |
| Network Interface | Ethernet RJ45 |
| Communication Speed | 10/100 Mbps |
| Network Standard | IEEE 802.3 / 802.3u Ethernet |
| Drive Connection Interface | 34-pin parallel bus connector |
| Power Supply | 5 V DC supplied from drive control board |
| Current Consumption | Approx. 380 mA at 5 V DC |
| Installation Type | Plug-in option module |
| Mounting Location | ABB drive control board option slot |
| Diagnostic Indicators | LED indicators for Link/Activity, Module Status, and Network Status |
| Configuration Method | Drive parameters and network configuration settings |
| Protection Class | IP20 |
| Operating Temperature | Up to +40°C ambient temperature |
| Cable Requirement | CAT 5 UTP/STP Ethernet cable |
| Connector Type | RJ45 Ethernet connector |
| Dimensions | Approx. 165 × 115 × 50 mm |
| Weight | Approx. 0.2 kg |
FAQ
FAQ
Q1: What is the ABB RETA-02 68840830 used for?
A: The ABB RETA-02 is an Ethernet communication adapter module that connects ABB drives to industrial Ethernet networks for remote control, monitoring, diagnostics, and parameter management.
Q2: Which ABB drives are compatible with RETA-02?
A: RETA-02 is commonly used with ABB ACS550, ACS800, ACS850, ACSM1, DCS800 and other compatible ABB drive platforms.
Q3: Which communication protocols does RETA-02 support?
A: The module supports PROFINET IO and Modbus/TCP industrial Ethernet protocols.
Q4: Is ABB RETA-02 a PLC communication module?
A: No. RETA-02 is a drive communication adapter. It allows ABB drives to communicate with PLCs and automation systems through Ethernet networks.
Q5: What is the power supply requirement of RETA-02?
A: The module receives a 5 V DC supply from the ABB drive control board through the internal connection interface.
Q6: What are the dimensions and weight of ABB RETA-02 68840830?
A: The approximate dimensions are 165 × 115 × 50 mm, and the weight is about 0.2 kg.
Q7: Does RETA-02 require software configuration?
A: Yes. Communication parameters, network settings, and drive-related functions need to be configured through the ABB drive parameters and the connected automation system.
Q8: What should be checked before installing ABB RETA-02?
A: Confirm drive compatibility, verify the module part number, check the Ethernet network settings, inspect connectors, and disconnect power before installing the communication module.
