Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | DCS800-S02-0260-05 |
| Part Number | 3AUA0000013767 |
| Product Type | DC Drive / DC Converter |
| Series | ABB DCS800 |
| Configuration | 4-Quadrant Reversing |
| Input Voltage | 230–525 VAC, 3-phase |
| Maximum Armature Current | 260 A DC |
| Armature Voltage | Up to 500 VDC |
| Internal Field Current | 15 A |
| Frame Size | D3 |
| Mounting | Wall-mounted |
| Enclosure | IP00, open chassis |
| Cooling | Forced air |
| Feedback | Armature / Tachometer / Encoder |
| Communication | RS-232 |
| Approx. Dimensions | 370 × 270 × 270 mm |
| Approx. Net Weight | 20 kg |
| Approx. Shipping Weight | 21–23 kg |
FAQ
FAQ
Q1: What is ABB DCS800-S02-0260-05?
A: It is an ABB DCS800 four-quadrant reversing DC drive designed for industrial DC motor control.
Q2: What is the ABB part number?
A: The ABB part number is 3AUA0000013767, corresponding to model DCS800-S02-0260-05.
Q3: What is the rated output current?
A: The model belongs to the 260 A DC current class, suitable for high-power DC motor applications.
Q4: What is the input voltage?
A: It is designed for a three-phase 230–525 VAC supply.
Q5: What is the maximum armature voltage?
A: The drive supports an armature voltage of up to approximately 500 VDC, depending on the selected AC supply configuration.
Q6: What does S02 mean?
A: S02 identifies the four-quadrant reversing configuration. It supports forward/reverse operation and regenerative braking.
Q7: What are the dimensions and weight?
A: For the D3 frame, a practical reference is approximately 370 × 270 × 270 mm and 20 kg net. Allow approximately 21–23 kg for packed shipping.
Q8: What is the difference between DCS800-S02-0260-05 and DCS800-S02-0200-05?
A: The main difference is the current rating. The 0260 version is rated for approximately 260 A, while the 0200 version is in the 190 A class. The 0260 therefore supports a higher-power DC motor application and uses the larger D3 frame.
