| Product Name | ABB DSQC 228 YB560103-BL/1 |
| Product Type | Robotics Safety Board / Control PCB |
| Manufacturer | ABB |
| Model Number | DSQC 228 |
| Part Number | YB560103-BL/1 |
| Application | ABB industrial robot control and safety systems |
| Function | Safety monitoring and axis control interface |
| System Compatibility | ABB robotic controllers and automation systems |
| Board Type | PCB control / safety board |
| Communication Interface | Internal controller backplane communication |
| Monitoring Functions | Safety system supervision and axis monitoring |
| Diagnostic Features | LED status indication and fault diagnostics |
| Mounting Type | Internal cabinet / controller board installation |
| Cooling Method | Passive cooling |
| Enclosure Type | Open PCB board |
| Supply Voltage | System-dependent internal DC supply |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Approx. 130 × 19 × 191 mm |
| Weight | Approx. 0.2 kg |
| Certifications | Industrial system dependent |
FAQ
FAQ
Q1: What is the ABB DSQC 228 YB560103-BL/1 used for?
The DSQC 228 YB560103-BL/1 is a robotics safety and control board used in ABB industrial robot control systems for monitoring safety functions and axis control operations.
Q2: Which systems commonly use this board?
It is commonly installed in ABB robotic controller systems and industrial automation platforms.
Q3: What is the primary function of the DSQC 228 board?
The board supervises safety-related signals, monitors system status, and supports communication between robot control components.
Q4: Does the module provide diagnostic functions?
Yes, the board includes LED-based diagnostic indicators for troubleshooting and system status monitoring.
Q5: Is this a standalone controller?
No, the DSQC 228 is an internal PCB module designed to operate inside ABB robotic control systems.
Q6: What happens if the safety circuit detects a fault?
The system may enter a protective shutdown or SYS HALT condition to prevent unsafe machine operation.
Q7: What type of cooling does the board require?
The module uses passive cooling and relies on the host control cabinet ventilation system.
Q8: Is the DSQC 228 still widely available?
The board is generally available through surplus, refurbished, and industrial spare parts suppliers, as it is mainly used in legacy ABB robotic systems.
