Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | NCHM-21C 64011332E |
| Type | Charging Monitoring Printed Circuit Board (PCB) |
| Function | Monitors and controls the charging status of inverter systems |
| Input Voltage | 24 V DC |
| Operating Voltage Range | 18 – 30 V DC |
| Current Consumption | 250 mA |
| Monitoring Channels | Dual-channel charge status monitoring |
| Signal Interface | Analog and digital I/O |
| Communication Protocol | RS-485 / Modbus RTU |
| LED Indicators | Power, Fault, and Charge Status Indicators |
| Diagnostics | Self-check and fault logging |
| Response Time | <10 ms |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -20°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | IEC 60068-2-6 compliant |
| EMC Compliance | IEC/EN 61800-3 compliant |
| Safety Standards | IEC/EN 61508 SIL2 compliant |
| Dimensions | 150 x 69 x 30 mm |
| Weight | 0.2 kg |
| Certifications | CE, RoHS |
FAQ
FAQ
Q1: What is the primary function of the NCHM-21C board?
A1: It monitors and manages the charging process of ABB inverter systems, ensuring safe and reliable operation.
Q2: What communication interfaces does the NCHM-21C support?
A2: It supports RS-485 communication and Modbus RTU protocol.
Q3: What is the response time of the NCHM-21C?
A3: It provides a fast response time of less than 10 milliseconds.
Q4: Does the board support self-diagnostics?
A4: Yes, it includes built-in self-diagnostic functions and fault logging.
Q5: What is the recommended input voltage for the NCHM-21C?
A5: The recommended input voltage is 24 V DC, with an operating range of 18 – 30 V DC.
Q6: What indicators are available on the board?
A6: It has LED indicators for Power, Fault, and Charge Status.
Q7: Is the NCHM-21C compliant with safety and EMC standards?
A7: Yes, it complies with IEC/EN 61508 SIL2 safety standards and IEC/EN 61800-3 EMC regulations.
Q8: How many monitoring channels does the NCHM-21C provide?
A8: It supports dual-channel charge status monitoring for precise control.
