Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | ABB NMTU-21C 3BSE017429R1 |
| Type | Digital Output Module |
| Output Channels | 16 Channels |
| Output Type | Digital (Relay/Transistor Configurable) |
| Max Output Voltage | 30V DC |
| Max Output Current | 0.5 A per channel |
| Response Time | < 1 ms |
| Control Interface | TTL Compatible / Logic Input |
| Signal Interface | Screw Terminal / Plug-in Connector |
| Isolation Method | Optical Isolation between channels |
| Isolation Voltage | ≥ 2.5 kVrms |
| Operating Temperature | -20°C ~ +70°C |
| Storage Temperature | -40°C ~ +85°C |
| Relative Humidity | 5% ~ 95% (Non-Condensing) |
| Dimensions | 90 x 75 x 60 mm |
| Weight | 0.35 kg |
| Certification | CE, UL |
FAQ
FAQ
-
How many output channels does the module support?
-
It provides 16 individually controllable digital output channels.
-
-
What types of outputs are available?
-
The outputs can be configured as relay or transistor digital outputs.
-
-
What is the maximum voltage for each output channel?
-
Each channel can handle up to 30V DC.
-
-
What is the maximum current per output channel?
-
Each channel can supply up to 0.5 A.
-
-
Which control interfaces are compatible with the module?
-
TTL logic level compatible inputs are supported.
-
-
Does the module provide electrical isolation between channels?
-
Yes, all channels are optically isolated.
-
-
What is the isolation voltage rating?
-
Isolation withstand voltage is ≥ 2.5 kVrms.
-
-
What is the response time of the digital outputs?
-
The response time is less than 1 ms.
-
