Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PD D163 A02 |
| Part Number | 3BHE013854R0002 |
| Manufacturer | ABB |
| Product Type | Circuit Board |
| Function | Serves as a signal processing and power distribution board in ABB industrial systems |
| Input Voltage Range | 18 – 32 V DC |
| Power Consumption | < 12 W |
| Input Signal Type | Analog and digital inputs |
| Output Signal Type | Logic-level digital outputs and analog control signals |
| Communication Interfaces | RS-485, CAN bus, and ABB proprietary interface |
| Processor Type | Embedded microcontroller for signal management and logic control |
| Operating Temperature Range | -20°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Isolation Voltage | 2.5 kV RMS between control and field circuits |
| Protection Functions | Overvoltage, short-circuit, and reverse polarity protection |
| Diagnostic Features | Built-in fault detection, status LED indicators, and error reporting |
| Signal Accuracy | ±0.5% of full-scale range |
| Response Time | < 5 ms |
| Supported Protocols | Modbus RTU, CANopen, ABB internal communication bus |
| Mounting Type | Panel or chassis mounting |
| Application Areas | Industrial drives, automation systems, power converters, and control units |
| Firmware Update Capability | Flash memory programmable via communication port |
| Compliance and Standards | CE, RoHS, and IEC 61131-2 compliant |
| Dimensions | 200 × 150 × 25 mm |
| Weight | 0.5 kg |
FAQ
FAQ
Q1: What is the primary purpose of the ABB PD D163 A02 Circuit Board?
It functions as a key control and signal interface board within ABB’s industrial automation systems, ensuring accurate data transmission and reliable system performance.
Q2: Which communication interfaces are available on this circuit board?
The board supports RS-485, CAN bus, and ABB’s proprietary communication link, allowing flexible integration with a range of control architectures.
Q3: What protection features are built into the PD D163 A02?
It includes comprehensive protection mechanisms such as overvoltage, short-circuit, and reverse polarity protection to enhance system safety and durability.
Q4: How does this board handle analog and digital signals?
The PD D163 A02 processes both analog and digital inputs efficiently, converting them into precise control signals for industrial equipment.
Q5: Can the firmware of the board be updated without removal?
Yes, the firmware can be updated in the field via its communication interface, making maintenance and system upgrades easier.
Q6: What kind of diagnostic capabilities does the board provide?
It features onboard fault detection, LED status indicators, and self-diagnostic functions to assist in system monitoring and troubleshooting.
Q7: In what types of ABB systems is the PD D163 A02 commonly used?
This circuit board is widely used in ABB drive systems, control modules, and power converter units for precise operational control.
Q8: What ensures stable operation under industrial conditions?
The board is built with industrial-grade components, high insulation voltage, and robust circuit protection to maintain stable performance even in harsh environments.
