Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PD D200 A101 |
| Part Number | 3BHE019633R0101 |
| Manufacturer | ABB |
| Product Type | Control Board |
| Function | Provides control and interface functions for ABB industrial automation systems |
| Input Voltage Range | 18 – 32 V DC |
| Power Consumption | < 15 W |
| Input Signal Type | Analog and digital inputs |
| Output Signal Type | Digital logic outputs and analog control signals |
| Communication Interfaces | RS-485, CAN bus, ABB proprietary communication |
| Processor Type | Embedded microcontroller for control and signal processing |
| Operating Temperature Range | -20°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Isolation Voltage | 2.5 kV RMS between control and field circuits |
| Protection Functions | Overvoltage, short-circuit, and reverse polarity protection |
| Diagnostic Features | Status LED indicators, built-in fault detection, error reporting |
| Signal Accuracy | ±0.5% of full-scale range |
| Response Time | < 5 ms |
| Supported Protocols | Modbus RTU, CANopen, ABB internal bus |
| Mounting Type | Panel or chassis mounting |
| Application Areas | Industrial drives, automation controllers, power converters |
| Firmware Update Capability | Flash memory programmable via communication port |
| Compliance and Standards | CE, RoHS, IEC 61131-2 compliant |
| Dimensions | 150 × 130 × 25 mm |
| Weight | 0.5 kg |
FAQ
FAQ
Q1: What is the main role of the ABB PD D200 A101 Control Board?
It serves as the central control module in ABB automation systems, managing signal processing, device interfacing, and operational logic.
Q2: Which types of input signals can the board process?
The PD D200 A101 handles both analog and digital inputs, converting them into precise control signals for connected devices.
Q3: What communication options are available for integration?
It supports RS-485, CAN bus, and ABB proprietary interfaces, providing flexible connectivity within industrial networks.
Q4: What protection features are included on this control board?
The board incorporates overvoltage protection, short-circuit protection, and reverse polarity safeguards to maintain system reliability.
Q5: How can firmware updates be performed on this board?
Firmware can be updated in the field via its communication port without removing the board, simplifying maintenance and upgrades.
Q6: What diagnostic capabilities does the board provide?
It includes built-in fault detection, status LED indicators, and error reporting to assist with monitoring and troubleshooting.
Q7: In which ABB systems is the PD D200 A101 typically installed?
It is commonly used in industrial drives, automation controllers, and power converter modules to ensure accurate control and communication.
Q8: How is reliable operation ensured in industrial environments?
Industrial-grade components, high insulation voltage, and comprehensive circuit protection provide stable performance under harsh conditions.
