Technical Specifications
| Parameter | Description |
|---|---|
| Model | SD831 |
| Article Number | 3BSC610064R1 |
| Type | Power Supply Module |
| Rated Output Voltage | 24 V DC |
| Max Output Current | 3.3 A |
| Rated Output Current | 3 A |
| Rated Output Power | 72 W |
| Input Voltage Range (AC) | 100–240 V AC ±10% |
| Input Voltage Range (DC) | 110–300 V DC (–20% / +25%) |
| Rated Input Power | 134 / 143 VA |
| Input Frequency | 50–60 Hz ±6% |
| Efficiency | 88% / 89.8% |
| Power Factor | 0.61 / 0.56 |
| Inrush Current at Power On | < 28 A / < 54 A |
| Output Voltage Regulation | < 50 mV / < 100 mV |
| Ripple (Peak-to-Peak) | < 50 mV |
| Hold-up Time | 29 / 120 ms |
| Output Overvoltage Protect | < 39 V |
| Recommended Input Fuse | 10–20 A |
| Output Short Circuit Prot. | 4–8 A |
| Max Ambient Temperature | 55°C |
| Protection Class | IP20 (IEC 60529) |
| Pollution Degree | Degree 2 (IEC 60664-1) |
| Electrical Safety | IEC 61131-2, UL 508, EN 50178 |
| EMC Compliance | EN 61000-6-2 and EN 61000-6-4 |
| Mounting Method | DIN Rail Mounting |
| Dimensions (W x H x D) | 32 x 124 x 102 mm |
| Weight | 0.52 kg |
| Marine Certification | ABS, BV, DNV-GL, LR |
| RoHS Compliance | Yes, per DIRECTIVE/2011/65/EU |
| WEEE Compliance | Yes, per DIRECTIVE/2012/19/EU |
FAQ
FAQ
Q1: What input voltage ranges does the SD831 support?
A1: It supports 100–240 V AC and 110–300 V DC input voltage ranges.
Q2: Can this module be used in redundant systems?
A2: Yes, it can be used in redundant systems with SS823 or SS832 diode voting units.
Q3: What is the maximum output current of the SD831?
A3: The maximum output current is 3.3 A; the rated output is 3 A.
Q4: Does it feature output overvoltage protection?
A4: Yes, the unit includes overvoltage protection, triggering below 39 V.
Q5: Is the SD831 compliant with industrial electrical safety standards?
A5: Yes, it complies with IEC 61131-2, UL 508, and EN 50178.
Q6: Is this module suitable for SELV/PELV applications?
A6: Yes, it is designed for SELV and PELV usage.
Q7: Does the module have marine certification?
A7: Yes, it is certified by ABS, BV, DNV-GL, and LR.
Q8: What is the protection rating of the SD831?
A8: The protection rating is IP20 according to IEC 60529.
