Technical Specifications
| Parameter | Value |
|---|---|
| Article Number | 3BSC610065R1 |
| Type | Power Supply Module |
| Rated Output Voltage | 24 V DC |
| Rated Output Current | 5 A |
| Maximum Output Current | 6 A (at ambient temperature < 45°C) |
| Rated Output Power | 120 W |
| Rated Input Power | 240 / 283 VA |
| Input Voltage Range | 100–120 V AC ±10% / 200–240 V AC ±10% (auto-select) |
| Input Frequency | 50–60 Hz ±6% |
| Inrush Current (Peak) | < 10 A |
| Output Voltage Regulation | < 70 mV / < 100 mV |
| Ripple (peak-to-peak) | < 50 mV |
| Holdup Time at Mains Blackout | 80 / 78 ms |
| Power Factor | 0.56 / 0.47 |
| Efficiency | 89.4% / 90.2% |
| Heat Dissipation | 14 / 13 W |
| Output Overvoltage Protection | < 39 V |
| External Fuse (Primary) | 10–20 A |
| Short Circuit (Secondary) | 10–14 A |
| Protection Rating | IP20 (IEC 60529) |
| Mounting | DIN-rail |
| Approvals / Certifications | CE, UL 508, EN 50178, IEC 61131-2, RoHS, WEEE |
| Marine Certifications | ABS, BV, DNV-GL, LR |
| Ambient Temperature Range | up to 55 °C |
| Pollution Degree | Degree 2 (IEC 60664-1) |
| Dimensions (W x H x D) | 32 x 124 x 117 mm |
| Weight | 0.56 kg |
FAQ
FAQ
Q1: What input voltages does the ABB SD832 support?
A1: It supports 100–120 V AC and 200–240 V AC with auto-select functionality.
Q2: Does this module have overvoltage protection?
A2: Yes, the output overvoltage protection is rated below 39 V.
Q3: What is the maximum output current of the SD832?
A3: It provides up to 6 A when ambient temperature is below 45°C.
Q4: What certifications does this module meet?
A4: It complies with CE, UL 508, EN 50178, and IEC 61131-2 standards.
Q5: Is the SD832 suitable for redundant power systems?
A5: Yes, it supports redundancy using diode voting units SS823 or SS832.
Q6: What is the installation method of the SD832?
A6: It uses DIN-rail mounting for easy installation.
Q7: What is the maximum operating temperature?
A7: The module operates up to an ambient temperature of 55°C.
Q8: Is the SD832 compliant with RoHS and WEEE directives?
A8: Yes, it meets RoHS (2011/65/EU) and WEEE (2012/19/EU) requirements.
