Technical Specifications
| Item | Description |
|---|---|
| Manufacturer | ABB |
| Product Model | SNAT7640 |
| Part Number | 3BSE003195R1 |
| Product Type | Control Card |
| Function | Provides control and communication functions within ABB process automation systems |
| System Compatibility | ABB Advant OCS and Symphony Plus control systems |
| Input/Output Channels | Multiple analog and digital I/O channels depending on configuration |
| Communication Interfaces | Advant Fieldbus, Ethernet, and serial communication |
| Processor Type | High-performance microprocessor for real-time control |
| Memory Capacity | Integrated program and data memory for system operation |
| Diagnostic Features | Built-in self-test and LED status indicators |
| Power Supply Voltage | 24 V DC (nominal) |
| Power Consumption | < 10 W |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Mounting Type | Rack-mounted in ABB system chassis |
| Cooling Method | Natural convection |
| Dimensions | 160 × 100 × 25 mm |
| Weight | 0.748 kg |
FAQ
FAQ
Q1: What is the ABB SNAT7640 3BSE003195R1 Control Card used for?
It is used for executing control logic and communication tasks in ABB process automation systems.
Q2: Which systems are compatible with the SNAT7640 card?
It is compatible with ABB Advant OCS and Symphony Plus control systems.
Q3: Does the module provide communication interfaces?
Yes, it supports Advant Fieldbus, Ethernet, and serial communication for data exchange.
Q4: What power supply is required for this module?
The SNAT7640 operates with a nominal 24 V DC power supply.
Q5: How does the module handle diagnostics?
It includes built-in self-test functions and LED indicators for system and communication status.
Q6: What is the operating temperature range of this card?
The module operates from 0°C to +55°C under normal conditions.
Q7: How is the module installed?
It is designed for rack-mount installation within ABB control system chassis.
Q8: What is the size and weight of the SNAT7640 module?
Its dimensions are 160 × 100 × 25 mm, and it weighs approximately 0.748 kg.
