Technical Specifications
| Item | Description |
|---|---|
| Manufacturer | ABB |
| Product Model | TC560V2 |
| Part Number | 3BSE022178R1 |
| Product Type | Fiber Optic Modem |
| Communication Type | Optical Fiber |
| Fiber Type | Multimode or Single-mode (depending on configuration) |
| Transmission Distance | Up to 15 km (single-mode) / Up to 2 km (multimode) |
| Baud Rate | Up to 115.2 kbps |
| Interface Type | RS-232 / RS-485 / RS-422 |
| Optical Connectors | ST or SC type |
| Power Supply Voltage | 24 V DC (nominal) |
| Power Consumption | < 5 W |
| Isolation Voltage | 2 kV between power, communication, and fiber ports |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | DIN rail or panel-mounted |
| Status Indicators | Power, Transmit, Receive, and Link LEDs |
| Dimensions | 216 x 54 x 153 mm |
| Weight | 0.75 kg |
FAQ
FAQ
Q1: What is the ABB TC560V2 3BSE022178R1 used for?
It is a fiber optic modem designed for industrial data transmission between control systems and remote equipment.
Q2: What types of fiber connections are supported?
The TC560V2 supports both single-mode and multimode optical fibers depending on the model version.
Q3: What is the maximum transmission distance?
Up to 15 km using single-mode fiber or 2 km using multimode fiber.
Q4: Which communication interfaces does it support?
It supports RS-232, RS-485, and RS-422 serial interfaces.
Q5: Can it be installed on a DIN rail?
Yes, the modem is designed for easy DIN rail or panel installation.
Q6: What power supply is required for operation?
It operates on a nominal 24 V DC power supply.
Q7: Are there LED indicators for operation status?
Yes, LED indicators display power, data transmission, reception, and link status.
Q8: What are the environmental limits for operation?
The modem operates between 0°C and +60°C with humidity up to 95% non-condensing.
