Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | ABB TY801K01 |
| Product ID | 3BSE023607R1 |
| Product Type | Terminal Base / Mounting Unit |
| Application | ABB S800 I/O system |
| Function | Provides mechanical support and terminal connections for one I/O module |
| Module Slots | 1 I/O module slot |
| Power Supply | 5 V DC via ModuleBus |
| Rated Current | 1.2 A |
| Communication | ModuleBus connection to I/O system |
| Electrical Connections | Screw terminal connections for field devices |
| Mounting Type | DIN‑rail mounting (TH35) |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Relative Humidity | 5% – 95% (non‑condensing) |
| Dimensions (W × H × D) | 45 × 119 × 71 mm |
| Weight | Approximately 0.13 kg |
| Compliance Standards | CE, RoHS, IEC 61131 |
FAQ
FAQ
Q1. What is the main purpose of the TY801K01?
It provides a stable base and terminal connections for one I/O module in the ABB S800 I/O system.
Q2. Which systems commonly use this terminal base?
It is designed for ABB S800 modular I/O systems used in industrial automation.
Q3. How many I/O modules can be mounted on the TY801K01?
Only one I/O module can be installed per base unit.
Q4. What type of power does the unit require?
It receives 5 V DC through the ModuleBus from the connected I/O system.
Q5. How is the unit installed in a control cabinet?
It is mounted on a standard DIN rail (TH35) for easy installation and modular assembly.
Q6. What protection rating does the unit provide?
The unit has an IP20 rating, suitable for installation inside protected electrical enclosures.
Q7. What are the recommended operating conditions?
Operating temperature: 0°C to +55°C; storage temperature: -25°C to +70°C; relative humidity: 5%–95%, non‑condensing.
Q8. What advantages does the TY801K01 provide in automation systems?
It simplifies wiring, ensures secure module mounting, and allows quick replacement of I/O modules in industrial control applications.
