Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Allen-Bradley 1606-XLP90E-2 |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Series | 1606-XLP Compact Power Supply Series |
| Product Type | DIN Rail Mounted Switching Power Supply |
| Function | Converts AC input power into regulated 24 VDC output power for industrial control systems |
| Application | PLC systems, industrial automation equipment, control cabinets, sensors, I/O modules, and auxiliary control circuits |
| Input Voltage | 380–480 VAC, 2-phase |
| Input Frequency | 47–63 Hz |
| Output Voltage | 24–28 VDC adjustable |
| Rated Output Voltage | 24 VDC |
| Output Power | 90 W |
| Rated Output Current | 3.75 A |
| Efficiency | Approx. 89.5% |
| Output Type | Stabilized DC output |
| Protection Features | Short-circuit protection, overload protection, overvoltage protection |
| Hold-Up Time | >93 ms at 480 VAC input |
| Mounting Type | DIN rail mounting |
| Electrical Connection | Spring-clamp terminal connection |
| LED Indicator | DC output status indication |
| Special Feature | NEC Class 2 power supply |
| IP Protection Rating | IP20 |
| Operating Temperature | -10°C to +60°C (application dependent) |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | <95%, non-condensing |
| MTBF | Approx. 1,594,000 hours at 40°C |
| Dimensions | 73 × 75 × 103 mm |
| Weight | Approx. 0.36 kg |
FAQ
FAQ
Q1: What is the Allen-Bradley 1606-XLP90E-2 used for?
A: The 1606-XLP90E-2 is used to provide stable 24 VDC power for industrial automation equipment, including PLCs, sensors, control modules, and other DC-powered devices.
Q2: What input voltage does the 1606-XLP90E-2 require?
A: It requires a 380–480 VAC two-phase input supply and is designed for industrial control cabinet applications.
Q3: What are the output specifications of the 1606-XLP90E-2?
A: The power supply provides an adjustable 24–28 VDC output, with a rated output power of 90 W and maximum output current of 3.75 A.
Q4: Can the 1606-XLP90E-2 be installed on a DIN rail?
A: Yes. The unit is designed for DIN rail mounting, making it suitable for compact industrial control panels.
Q5: Does the 1606-XLP90E-2 have protection functions?
A: Yes. It includes protection features such as overload protection, short-circuit protection, and regulated output voltage to improve system reliability.
Q6: What are the dimensions and weight of the 1606-XLP90E-2?
A: The approximate dimensions are 73 × 75 × 103 mm, and the weight is approximately 0.36 kg.
Q7: What applications commonly use the 1606-XLP90E-2?
A: It is commonly used in PLC control cabinets, factory automation systems, machine control equipment, and industrial instrumentation requiring reliable 24 VDC power.
Q8: What should be checked before installing the 1606-XLP90E-2?
A: Verify the AC input voltage, DC load requirements, wiring connections, mounting space, and grounding conditions before installation. Ens
