Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Allen-Bradley 1732E-16CFGM12P5QCWR |
| Product Type | ArmorBlock Guard I/O Safety Module |
| Series | Bulletin 1732E ArmorBlock |
| Communication Protocol | EtherNet/IP |
| Number of Inputs | 16 Configurable Safety Inputs |
| Input Type | PNP |
| Connector Type | M12 Quick Disconnect |
| Ports | 5-Pin M12 |
| Operating Voltage | 24V DC |
| Voltage Range | 19.2–28.8V DC |
| Current Consumption | 400 mA Maximum |
| Housing Material | Die-Cast Zinc |
| Protection Rating | IP65/IP67/IP69K |
| Mounting Type | Machine Mount |
| Operating Temperature | -20°C to +60°C |
| Shock Resistance | 30 g |
| Vibration Resistance | 5 g |
| Dimensions (L × W × H) | 224 × 58 × 39 mm |
| Weight | 0.95 kg |
| Certifications | CE, UL, cULus, TÜV |
| Product Status | Active |
FAQ
FAQ
Q1: What is the main function of the 1732E-16CFGM12P5QCWR module?
The module provides distributed safety I/O connectivity for industrial EtherNet/IP safety systems.
Q2: How many safety inputs are included?
The unit includes 16 configurable safety input channels.
Q3: What communication protocol does the module use?
It communicates through EtherNet/IP networks.
Q4: What type of connector is used on the module?
The module uses M12 quick-disconnect connectors with 5-pin ports.
Q5: Is the 1732E-16CFGM12P5QCWR suitable for harsh environments?
Yes, it features IP65, IP67, and IP69K protection ratings for demanding industrial applications.
Q6: What mounting method is supported?
The module is designed for direct machine mounting without a control cabinet.
Q7: What are the dimensions and weight of the unit?
The dimensions are 224 × 58 × 39 mm, and the weight is approximately 0.95 kg.
Q8: Is the 1732E-16CFGM12P5QCWR still available?
Yes, the product is currently listed as active within the ArmorBlock Guard I/O product line.
