Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Allen-Bradley 1756-EN3TRK |
| Product Type | EtherNet/IP Communication Module |
| Series | ControlLogix |
| Communication Protocol | EtherNet/IP |
| Ethernet Interface | 2 RJ45 Copper Ports |
| Communication Speed | 10/100/1000 Mbps (Gigabit Ethernet) |
| Network Topologies | Device Level Ring (DLR), Linear, Star |
| Embedded Switch | Yes |
| Maximum CIP Connections | 256 |
| Maximum TCP/IP Connections | 128 |
| Supported Motion Axes | Up to 100 Axes |
| Time Synchronization | CIP Sync, IEEE 1588 |
| USB Port | USB 2.0 |
| Security Features | Secure Device Authentication |
| Special Features | Conformal Coating |
| Backplane Current Consumption | 1.2 A @ 5.1V DC |
| Power Dissipation | 6.2 W |
| Isolation Voltage | 30V Continuous |
| Mounting Type | ControlLogix Chassis Mount |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% Non-Condensing |
| Dimensions (H × W × D) | 145 × 35 × 140 mm |
| Weight | 0.31 kg |
| Certifications | UL, CE, CSA, ATEX, IECEx |
| Product Status | Active |
FAQ
FAQ
Q1: What is the primary function of the 1756-EN3TRK module?
The module provides high-speed EtherNet/IP communication for ControlLogix automation systems with integrated switching capabilities.
Q2: What Ethernet speeds are supported?
The module supports 10 Mbps, 100 Mbps, and 1 Gbps Ethernet communication.
Q3: How many Ethernet ports are available?
The module includes two RJ45 Gigabit Ethernet ports with an embedded switch.
Q4: Which network topologies are supported?
It supports Device Level Ring (DLR), linear, and star network topologies.
Q5: Does the module support motion control applications?
Yes, it supports integrated motion applications with up to 100 motion axes.
Q6: What synchronization technologies are supported?
The module supports CIP Sync and IEEE 1588 Precision Time Protocol.
Q7: What are the dimensions and weight of the unit?
The dimensions are 145 × 35 × 140 mm, and the weight is approximately 0.31 kg.
Q8: Is the 1756-EN3TRK still available?
Yes, the product is currently active within the Allen-Bradley ControlLogix platform.
