Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-IR6I/A |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix Output Module |
| Module Function | 6-Channel Isolated DC Digital Output Module (High-Side) |
| Output Type | Sourcing DC voltage (high-side) |
| Output Voltage Range | 10–31.2 V DC (nominal 24 V DC) |
| Number of Channels | 6 |
| Output Current | 0.5 A per channel (max) |
| Isolation Voltage | 250V channel-to-channel and channel-to-backplane |
| Backplane Current Consumption | 250 mA at 5.1V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Shock Rating | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm (5.7 in × 1.4 in × 5.5 in) |
| Weight | 0.33 kg (0.73 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756-IR6I/A module?
It provides 6 isolated high-side DC digital output channels for ControlLogix systems.
Q2. What does the “/A” designation mean?
It indicates Series A hardware revision of the module.
Q3. What type of outputs does it support?
Sourcing DC voltage (high-side) outputs.
Q4. How many output channels are available?
6 independent isolated channels.
Q5. What is the maximum output current per channel?
0.5 A per channel.
Q6. What does “isolated” mean for this module?
Each channel is electrically isolated from other channels and the backplane to improve safety and noise immunity.
Q7. Can it be installed in any ControlLogix chassis?
Yes, it fits standard ControlLogix chassis slots.
Q8. Where is this module typically used?
In industrial automation systems for safely controlling actuators, relays, and other DC-powered field devices.
