Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-IT16 |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix Output Module |
| Module Function | 16-Channel DC Digital Output Module (Pulse/Timed) |
| Output Type | Sinking DC voltage |
| Output Voltage Range | 10–31.2 V DC (nominal 24 V DC) |
| Number of Channels | 16 |
| Output Current | 0.5 A per channel (max) |
| Isolation Voltage | 30V continuous |
| Backplane Current Consumption | 250 mA at 5.1V DC |
| Pulse/Timed Capability | Supports output pulse timing for motion or sequencing applications |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Shock Rating | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm (5.7 in × 1.4 in × 5.5 in) |
| Weight | 0.34 kg (0.75 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756-IT16 module?
It provides 16 DC digital output channels with pulse/timed capability for ControlLogix systems.
Q2. What type of outputs does it support?
Sinking DC voltage outputs.
Q3. How many output channels are available?
16 channels.
Q4. What is the maximum output current per channel?
0.5 A per channel.
Q5. What does “pulse/timed” capability mean?
It allows outputs to be controlled with precise timing or pulses for motion or sequencing tasks.
Q6. Is the module isolated?
It has basic isolation with 30V continuous rating.
Q7. Can it be installed in any ControlLogix chassis?
Yes, it is compatible with standard ControlLogix chassis slots.
Q8. Where is this module typically used?
In industrial automation systems requiring timed or pulsed DC output control, such as motion control or sequencing applications.
