Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-IT6I |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix Output Module |
| Module Function | 6-Channel Isolated DC Digital Output Module (Pulse/Timed, High-Side) |
| Output Type | Sourcing DC voltage (high-side) |
| Output Voltage Range | 10–31.2 V DC (nominal 24 V DC) |
| Number of Channels | 6 |
| Output Current | 0.5 A per channel (max) |
| Isolation Voltage | 250V channel-to-channel and channel-to-backplane |
| Backplane Current Consumption | 250 mA at 5.1V DC |
| Pulse/Timed Capability | Supports output pulse timing for motion or sequencing applications |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Shock Rating | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm (5.7 in × 1.4 in × 5.5 in) |
| Weight | 0.34 kg (0.75 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756-IT6I module?
It provides 6 isolated high-side DC digital output channels with pulse/timed capability for ControlLogix systems.
Q2. What type of outputs does it support?
Sourcing DC voltage (high-side).
Q3. How many output channels are available?
6 independent isolated channels.
Q4. What is the maximum output current per channel?
0.5 A per channel.
Q5. What does “pulse/timed” capability mean?
It allows outputs to operate with precise timing or pulses for motion or sequencing tasks.
Q6. What does “isolated” mean for this module?
Each channel is electrically isolated from others and the backplane to improve safety and noise immunity.
Q7. Can it be installed in any ControlLogix chassis?
Yes, it fits standard ControlLogix chassis slots.
Q8. Where is this module typically used?
In industrial automation systems requiring timed or pulsed DC output control with isolation, such as motion control, sequencing, or actuator control.
