Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-IT6I2 |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix Output Module |
| Module Function | 6-Channel Isolated DC Digital Output Module (High-Speed/High-Side) |
| Output Type | Sourcing DC voltage (high-side) |
| Output Voltage Range | 10–31.2 V DC (nominal 24 V DC) |
| Number of Channels | 6 |
| Output Current | 0.5 A per channel (max) |
| Isolation Voltage | 250V channel-to-channel and channel-to-backplane |
| Backplane Current Consumption | 250 mA at 5.1V DC |
| Pulse/Timed Capability | Supports high-speed output pulses for motion and sequencing |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Shock Rating | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm (5.7 in × 1.4 in × 5.5 in) |
| Weight | 0.34 kg (0.75 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756-IT6I2 module?
It provides 6 isolated high-side DC digital output channels with high-speed pulse/timed capability.
Q2. What type of outputs does it support?
Sourcing DC voltage (high-side) outputs.
Q3. How many output channels are available?
6 independent isolated channels.
Q4. What is the maximum output current per channel?
0.5 A per channel.
Q5. What does “high-speed/pulse” capability mean?
It allows outputs to generate fast pulses for motion control and sequencing applications.
Q6. What does “isolated” mean for this module?
Each channel is electrically isolated from other channels and the backplane for safety and noise immunity.
Q7. Can it be installed in any ControlLogix chassis?
Yes, it fits standard ControlLogix chassis slots.
Q8. Where is this module typically used?
In industrial automation systems requiring high-speed DC output control, such as motion control, actuators, and sequencing systems.
