Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-IV32 |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix Output Module |
| Module Function | 32-Channel Isolated DC Digital Output Module |
| Output Type | Sourcing DC voltage |
| Output Voltage Range | 10–31.2 V DC (nominal 24 V DC) |
| Number of Channels | 32 |
| Output Current | 0.5 A per channel (max) |
| Isolation Voltage | 250V channel-to-channel and channel-to-backplane |
| Backplane Current Consumption | 500 mA at 5.1V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Shock Rating | 30 g |
| Dimensions | 145 mm × 70 mm × 140 mm (5.7 in × 2.8 in × 5.5 in) |
| Weight | 0.55 kg (1.21 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756-IV32 module?
It provides 32 isolated DC digital output channels for ControlLogix systems.
Q2. What type of outputs does it support?
Sourcing DC voltage outputs.
Q3. How many output channels are available?
32 independent isolated channels.
Q4. What is the maximum output current per channel?
0.5 A per channel.
Q5. What does “isolated” mean for this module?
Each channel is electrically isolated from others and the backplane for safety and noise immunity.
Q6. Can it be installed in any ControlLogix chassis?
Yes, it fits standard ControlLogix chassis slots.
Q7. Is the module hot-swappable?
Yes, it supports insertion or removal under power with proper precautions.
Q8. Where is this module typically used?
In industrial automation systems requiring a large number of isolated DC outputs to control actuators, relays, or other field devices.
