Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-L1M2 |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix Power Supply |
| Module Function | 1.25 A Redundant Power Supply Module |
| Output Voltage | 24 V DC nominal |
| Output Current | 1.25 A maximum |
| Input Voltage | 85–264 V AC, 47–63 Hz |
| Number of Outputs | 1 redundant output |
| Efficiency | 85% typical |
| Ripple & Noise | <50 mV peak-to-peak |
| Backplane Current | N/A (self-powered) |
| Operating Temperature | 0 to 55°C (32 to 131°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration | 2 g (10–500 Hz) |
| Shock | 30 g |
| Dimensions | 140 mm × 35 mm × 140 mm (5.5 in × 1.4 in × 5.5 in) |
| Weight | 0.40 kg (0.88 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the function of the 1756-L1M2 module?
It provides a redundant 24 V DC power supply for ControlLogix systems.
Q2. What is the maximum output current?
1.25 A.
Q3. What input voltages are supported?
85–264 V AC at 47–63 Hz.
Q4. How does redundancy work in this module?
It can operate alongside another 1756-L1M2 to provide a backup in case one supply fails.
Q5. What is the typical efficiency?
Approximately 85%.
Q6. Can it be installed in any ControlLogix chassis?
Yes, it is designed for standard ControlLogix chassis slots.
Q7. Is the module hot-swappable?
Yes, it supports insertion or removal under proper power conditions.
Q8. Where is this module typically used?
In industrial automation systems where reliable redundant power is required for ControlLogix controllers and modules.
