Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-L64 |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix Programmable Automation Controller |
| Module Function | Logix5564 Controller (Processor Module) |
| User Memory | 16 MB |
| I/O Memory | 478 KB |
| Maximum I/O | 128,000 total I/O points |
| Maximum Digital I/O | 128,000 |
| Maximum Analog I/O | 4,000 |
| Tasks Supported | Up to 32 tasks, 100 programs per task |
| Communication Port | 1 × RS-232 serial port |
| Optional Communication | EtherNet/IP, ControlNet, DeviceNet, DH+, Remote I/O (via modules) |
| Controller Connections | Up to 250 connections |
| Backplane Current Consumption | 1200 mA @ 5.1V DC; 14 mA @ 24V DC |
| Power Dissipation | 3.5 W |
| Isolation Voltage | 30V continuous |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration Rating | 2 g (10–500 Hz) |
| Dimensions | 222 mm × 181 mm × 54 mm |
| Weight | 0.32–0.50 kg |
| Installation | ControlLogix chassis slot |
| Lifecycle Status | Discontinued (since 2017) |
| Certifications | CE, UL |
FAQ
FAQ
Q1. What is the function of the 1756-L64 module?
It is a ControlLogix controller used to execute control logic and manage industrial automation systems.
Q2. How much memory does it have?
It provides 16 MB of user memory and 478 KB of I/O memory.
Q3. What is the maximum I/O capacity?
Up to 128,000 total I/O points, including 4,000 analog channels.
Q4. What communication options are available?
It includes an RS-232 port and supports multiple industrial networks via additional communication modules.
Q5. How many tasks can it handle?
Up to 32 tasks with multiple programs per task.
Q6. Does it support redundancy?
Yes, it supports controller redundancy for high-availability systems.
Q7. Is this module still available?
No, it has been discontinued and replaced by newer ControlLogix controllers.
Q8. Where is this module typically used?
In complex industrial automation systems requiring high processing capability, large I/O handling, and flexible communication options.
