Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-L73S |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix GuardLogix Controller |
| Module Function | Logix5573S Safety‑Enabled Processor |
| User Memory | 8 MB |
| Safety Memory | 1–2 MB safety partition |
| I/O Memory | 0.98 MB |
| Non‑volatile Memory | Removable SD card slot |
| Maximum I/O | 128,000 total I/O points |
| Maximum Digital I/O | 128,000 |
| Maximum Analog I/O | 4,000 |
| Tasks Supported | Up to 31 standard tasks; 1 safety task |
| Communication Port | 1 × USB 2.0 (programming) |
| Optional Network Adapters | EtherNet/IP, ControlNet, DeviceNet |
| Controller Connections | Varies by adapter module |
| Backplane Current Consumption | ~800 mA @ 5.1V DC; 5 mA @ 1.2V DC |
| Power Dissipation | ~2.5 W |
| Isolation Voltage | 30V continuous |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non‑condensing |
| Vibration | 2 g (10–500 Hz) |
| Shock | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm |
| Weight | 0.26 kg (0.57 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA (Safety standards compliant) |
FAQ
FAQ
Q1. What is the function of the 1756-L73S module?
It is a GuardLogix safety‑enabled controller that runs both standard and safety logic in a ControlLogix system.
Q2. How much memory does it have?
It provides 8 MB user memory, dedicated safety memory, and I/O memory.
Q3. What safety capability does it support?
It supports integrated safety tasks compliant with SIL3/PLe when paired with appropriate safety I/O.
Q4. What I/O capacity can this controller handle?
Up to 128,000 total I/O points including digital and analog.
Q5. Does it include networking interfaces?
It has a USB programming port and supports optional network modules (EtherNet/IP, ControlNet, DeviceNet).
Q6. How many tasks can it run?
It supports up to 31 standard tasks and one safety task.
Q7. Can it be installed in any ControlLogix chassis?
Yes, it fits in standard ControlLogix 1756 series chassis slots.
Q8. Where is this module typically used?
In industrial automation systems requiring integrated safety control along with standard automation functionality, such as machinery safety and process guarding.
