Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-L73XT |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix GuardLogix Controller |
| Module Function | Logix5573XT Safety‑Enabled Processor |
| User Memory | 8 MB |
| Safety Memory | 2 MB dedicated safety partition |
| I/O Memory | 0.98 MB |
| Non‑volatile Memory | Removable SD card support |
| Maximum I/O | 128,000 total I/O points |
| Maximum Digital I/O | 128,000 |
| Maximum Analog I/O | 4,000 |
| Tasks Supported | Up to 31 standard tasks; 1 safety task |
| Communication Port | 1 × USB 2.0 |
| Optional Communication | Adapter modules (EtherNet/IP, ControlNet, etc.) |
| Controller Connections | Varies by network adapter |
| Backplane Current Consumption | ~800 mA @ 5.1V DC; 5 mA @ 1.2V DC |
| Power Dissipation | ~2.5 W |
| Isolation Voltage | 30V continuous |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non‑condensing |
| Vibration | 2 g (10–500 Hz) |
| Shock | 30 g |
| Dimensions | 145 mm × 35 mm × 140 mm |
| Weight | 0.26 kg (0.57 lb) |
| Installation | ControlLogix 1756 chassis slot |
| Certifications | CE, UL, CSA; Safety standards compliant |
FAQ
FAQ
Q1. What is the function of the 1756-L73XT module?
It is a GuardLogix safety‑enabled controller that executes both standard and safety logic.
Q2. How much memory does it provide?
It provides 8 MB of user memory and 2 MB of safety memory.
Q3. What is the difference between L73S and L73XT?
The L73XT includes extended safety memory and features for more complex safety applications.
Q4. What communication interfaces are available?
It has a USB programming port and supports optional network adapter modules.
Q5. What is the maximum I/O capacity?
Up to 128,000 total I/O points including digital and analog I/O.
Q6. How many tasks can it run?
It supports up to 31 standard tasks and one safety task.
Q7. Can it be installed in any ControlLogix chassis?
Yes, it installs in standard ControlLogix 1756 chassis slots.
Q8. Where is this module typically used?
In industrial automation systems requiring high‑level safety control integrated with general automation functions.
