Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-L82E |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix 5580 Programmable Automation Controller |
| Module Function | High-performance PAC (Processor Module) |
| User Memory | 10 MB |
| I/O Memory | 1 MB |
| Non-volatile Memory | SD card slot (supports removable SD cards) |
| Maximum I/O | 128,000 total I/O points |
| Maximum Digital I/O | 128,000 |
| Maximum Analog I/O | 4,000 |
| Communication Ports | 1 × Gigabit Ethernet, 1 × USB 2.0 |
| Ethernet Speed | 10/100/1000 Mbps |
| Tasks Supported | Up to 32 tasks, 100 programs per task |
| Controller Connections | Up to 256 (depends on configuration) |
| Backplane Current Consumption | ~1.20 A @ 5.1V DC; ~5 mA @ 1.2V DC |
| Power Dissipation | ~6.2 W |
| Isolation Voltage | 50V continuous |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration | 2 g (10–500 Hz) |
| Shock | 30 g |
| Dimensions | 145 mm × 34.5 mm × 136.5 mm |
| Weight | 0.44 kg (0.97 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA |
FAQ
FAQ
Q1. What is the 1756-L82E used for?
It is a high-performance ControlLogix 5580 controller used for advanced industrial automation and control tasks.
Q2. How much memory does it provide?
It includes 10 MB of user memory and 1 MB of I/O memory.
Q3. What communication interfaces are built in?
It features a Gigabit Ethernet port and a USB 2.0 port for programming.
Q4. What is the maximum I/O capacity?
Up to 128,000 total I/O points, including digital and analog.
Q5. Does it support removable storage?
Yes, it supports SD cards for non-volatile storage.
Q6. How many tasks can it handle?
It supports up to 32 tasks with multiple programs per task.
Q7. Can it be installed in any ControlLogix chassis?
Yes, it is compatible with standard 1756 ControlLogix chassis.
Q8. Where is this controller typically used?
In large-scale automation systems requiring high processing speed, integrated Ethernet communication, and flexible I/O handling.
