Technical Specifications
| Description | Parameter |
|---|---|
| Product Model | 1756-L82ES |
| Manufacturer | Allen-Bradley |
| Product Type | ControlLogix 5580 GuardLogix Controller |
| Module Function | Safety-enabled Programmable Automation Controller |
| User Memory | 10 MB |
| Safety Memory | ~5 MB safety partition |
| I/O Memory | 1 MB |
| Non-volatile Memory | SD card slot (supports removable SD cards) |
| Maximum I/O | 128,000 total I/O points |
| Maximum Digital I/O | 128,000 |
| Maximum Analog I/O | 4,000 |
| Communication Ports | 1 × Gigabit Ethernet, 1 × USB 2.0 |
| Ethernet Speed | 10/100/1000 Mbps |
| Tasks Supported | Up to 31 standard tasks; 1 safety task |
| Controller Connections | Up to 256 (depends on configuration) |
| Backplane Current Consumption | ~1.20 A @ 5.1V DC; ~5 mA @ 1.2V DC |
| Power Dissipation | ~6.2 W |
| Isolation Voltage | 50V continuous |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Humidity | 5–95% non-condensing |
| Vibration | 2 g (10–500 Hz) |
| Shock | 30 g |
| Dimensions | 145 mm × 34.5 mm × 136.5 mm |
| Weight | 0.45 kg (0.99 lb) |
| Installation | ControlLogix chassis slot |
| Certifications | CE, UL, CSA, SIL3, PLe |
FAQ
FAQ
Q1. What is the 1756-L82ES module used for?
It is a GuardLogix 5580 safety controller used for integrated standard and safety automation control.
Q2. How much memory does it provide?
It includes 10 MB of user memory and a dedicated safety memory partition.
Q3. What safety level does it support?
It supports high-level safety applications up to SIL3 and PLe when properly configured.
Q4. What communication interfaces are built in?
It features a Gigabit Ethernet port and a USB port for programming.
Q5. What is the maximum I/O capacity?
Up to 128,000 total I/O points, including analog and digital.
Q6. How many tasks can it run?
It supports up to 31 standard tasks and one dedicated safety task.
Q7. Does it support removable storage?
Yes, it supports SD cards for program and data storage.
Q8. Where is this controller typically used?
In industrial automation systems requiring both high-performance control and integrated functional safety.
