Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | ControlLogix 5580 Process Controllers |
| Model Number | 1756-L83EP |
| Product Type | Process Controller / PLC CPU |
| Controller Family | ControlLogix 5580 |
| User Memory | 10 MB |
| Nonvolatile Memory | Secure Digital (SD) Card Supported |
| Embedded Ethernet Port | 1 × 1 Gigabit EtherNet/IP Port |
| USB Port | 1 × USB 2.0 |
| Supported EtherNet/IP Nodes | Up to 250 Nodes |
| Programming Languages | Ladder Logic, Structured Text, Function Block, Sequential Function Chart |
| Number of Tasks | Up to 32 |
| Programs per Task | Up to 1000 |
| Maximum Digital I/O | Up to 128,000 Points |
| Maximum Analog I/O | Up to 4,000 Points |
| Conformal Coating | Yes |
| Display Type | 4-character Alphanumeric Display |
| Backplane Current Draw | 1.2 A @ 5.1V DC, 5 mA @ 1.2V DC |
| Power Dissipation | Approx. 6.2 W |
| Thermal Dissipation | Approx. 21.2 BTU/hr |
| Isolation Voltage | 50V Continuous |
| Mounting Type | ControlLogix Chassis Mount |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, ATEX, IECEx, KC, RCM |
| Lifecycle Status | End of Life Announced (Discontinued after Dec 31, 2026) |
| Recommended Replacement | 1756-L83EPXT |
| Actual Dimensions (H × W × D) | Approx. 145 × 145 × 55 mm |
| Actual Weight | Approx. 0.96 kg |
| Typical Applications | Process Automation, PlantPAx, High-speed Industrial Control, EtherNet/IP Systems |
FAQ
FAQ
Q1: What is the Allen-Bradley 1756-L83EP used for?
A1: The 1756-L83EP is a high-performance ControlLogix 5580 process controller designed for large-scale industrial automation and PlantPAx process control systems.
Q2: How much memory does the 1756-L83EP provide?
A2: The controller includes 10 MB of user memory and supports SD card nonvolatile memory storage.
Q3: What communication ports are built into the 1756-L83EP?
A3: The controller includes one embedded 1 Gigabit EtherNet/IP port and one USB programming port.
Q4: How many EtherNet/IP devices can the 1756-L83EP support?
A4: The controller supports up to 250 EtherNet/IP nodes depending on system architecture and firmware configuration.
Q5: What are the actual dimensions and weight of the 1756-L83EP?
A5: The approximate dimensions are 145 × 145 × 55 mm and the approximate weight is 0.96 kg.
Q6: Is the 1756-L83EP conformal coated?
A6: Yes. The controller includes conformal coating for improved environmental protection in industrial applications.
Q7: What is the lifecycle status of the 1756-L83EP?
A7: Rockwell Automation announced end-of-life status for the 1756-L83EP, with discontinuation effective December 31, 2026. The recommended direct replacement is the 1756-L83EPXT.
Q8: What are common applications for the 1756-L83EP?
A8: Common applications include process control, PlantPAx distributed control systems, oil & gas facilities, chemical plants, power generation, and large-scale manufacturing automation.
