Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | SLC 500 |
| Model Number | 1747-AENTR |
| Product Type | EtherNet/IP Adapter Module |
| Function | SLC 500 EtherNet/IP Communication Adapter |
| Module Location | Slot 0 (Leftmost Slot) |
| Ethernet Ports | 2 × RJ45 Embedded Switch Ports |
| Ethernet Speed | 10/100 Mbps, Half/Full Duplex |
| Supported Topologies | Star, Linear, Tree, Ring |
| Ethernet Protocol | EtherNet/IP |
| Interface Type | RJ45 Category 5 |
| Backplane Current Consumption | 470 mA @ 5V DC |
| Thermal Dissipation | 2.49 W |
| Isolation Voltage | 50V Continuous |
| Enclosure Type | Open Type / IP20 |
| Mounting | SLC 500 Chassis Mount |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, cUL |
| Lifecycle Status | Active Mature |
| Actual Dimensions (H × W × D) | 145.3 × 34.8 × 130.8 mm |
| Actual Weight | Approx. 0.168 kg |
| Typical Applications | SLC Migration, EtherNet/IP Integration, Industrial PLC Networking |
FAQ
FAQ
Q1: What is the Allen-Bradley 1747-AENTR used for?
A1: The 1747-AENTR is an EtherNet/IP adapter module used to connect SLC 500 I/O chassis to EtherNet/IP networks and modern Logix systems.
Q2: Where is the 1747-AENTR installed in the chassis?
A2: The module must always be installed in Slot 0, the leftmost slot of the SLC 500 chassis.
Q3: How many Ethernet ports does the 1747-AENTR provide?
A3: The adapter includes two embedded RJ45 Ethernet ports supporting 10/100 Mbps communication.
Q4: What network topologies are supported by the 1747-AENTR?
A4: The module supports star, linear/daisy-chain, tree, and ring Ethernet topologies.
Q5: What are the actual dimensions of the 1747-AENTR?
A5: The approximate dimensions are 145.3 × 34.8 × 130.8 mm (H × W × D).
Q6: What is the actual weight of the 1747-AENTR?
A6: The actual weight is approximately 0.168 kg (168 g).
Q7: What power does the 1747-AENTR consume?
A7: The module draws approximately 470 mA from the SLC backplane at 5V DC.
Q8: What are common applications for the 1747-AENTR?
A8: Common applications include migrating legacy SLC 500 systems to EtherNet/IP networks, integrating SLC I/O into ControlLogix or CompactLogix systems, and industrial automation networking.
